FHSD700C Series Product Guide
GE Security
Table 5-4: Configuration Mode Parameters and Values
Parameter Range Factory
Default
OPCODE Operator Function Access Code 0 to 999 0
ENDSCTR End Sector (number of sectors used) 1 - default 4, 6, 8 or 15
DENSLOG Log of density change 0.01 to 20.00 0.02
F2LTCH Fire 2 Latch 0 or 1 1
F1LTCH Fire 1 Latch 0 or 1 1
ACTLTCH Action Latch 0 or 1 1
ALTLTCH Alert Latch 0 or 1 1
TRCLTCH Trace Latch 0 or 1 1
FLTLTCH Fault Latch 0 or 1 1
TRCRLY Trace Relay 1 0 or 1 0
REFCOMP Reference Compensation 0 to 5% 2.00%
REFDEL Reference Delay 5 to 60s 15s
FLOWDEL Flow Fault Delay 1 to 60s 5s
FLOWHI Flow High Limit 105 to 200% 120%
FLOWLO Flow Low Limit 0 to 95% 80%
FLOWLOG Log of flow change 0.0 to 200.0 5.0
SETFAN Set Fan Speed 3 to 10 5
STANDBY Battery Charger Enable 0 or 1 0
PWRDEL AC power supply fail delay 1 to 1000s 10s
BUZZER Internal Sounder Enable 0 or 1 1
BEACON Beacon Enable 0 or 1 1
ADDRESS RS485 Address 0 to 30 31 (off)
TESTTIM Time between automatic scans
Note: TESTIM is also used for FHSD700C-15 Flow normalization by
pressing ENTER
0 to 30 mins 20
MIN DWELL Rotary valve dwell time 0 to 60s 0s
GAIN X See description
MOD1 Set Module 1 usage
MOD2 Set Module 2 usage
MOD3 Set Module 3 usage
MOD4 Set Module 4 usage
MOD5 Set Module 5 usage
SC DEL Suppression Control Delay 0 to 120 60
NIGHSTART Night Start time (Hour in 24 format) 12 to 23 12
NIGHSTOP Night Stop time (Hour in 24 format) 0 to 12 12
TRC PRESS Setup for auto Valve Scan 5 to 1000 25
Note: Avoid setting to values already defined for Level 1 or 2 Access Codes.
Note: When Standby is set to 1, the panel display will switch off if the AC mains supply is removed.
Note: To revert all Configuration parameters to their default values go to the LOAD DEFAULTS menu
item and press ENTER (Level 2 Access Code is required). The Unit will restart with default
parameters.
