Up to 256 binary input points can be configured for the DNP or IEC 60870-5-104 protocols. The points are configured by
assigning an appropriate FlexLogic operand. Refer to the Introduction to FlexLogic section in this chapter for the full range
of assignable operands.
The menu for the analog input points (DNP) or MME points (IEC 60870-5-104) is shown below.
PATH: SETTINGS  PRODUCT SETUP  COMMUNICATIONS  DNP / IEC104 POINT LISTS  ANALOG INPUT / MME POINTS
Up to 256 analog input points can be configured for the DNP or IEC 60870-5-104 protocols. The analog point list is config-
ured by assigning an appropriate FlexAnalog parameter to each point. Refer to Appendix A: FlexAnalog Parameters for the
full range of assignable parameters.
The DNP / IEC 60870-5-104 point lists always begin with point 0 and end at the first “Off” value. Since DNP / IEC
60870-5-104 point lists must be in one continuous block, any points assigned after the first “Off” point are ignored.
Changes to the DNP / IEC 60870-5-104 point lists will not take effect until the G60 is restarted.
k) IEC 61850 PROTOCOL
PATH: SETTINGS  PRODUCT SETUP  COMMUNICATIONS  IEC 61850 PROTOCOL
 ANALOG INPUT / MME
 POINTS
Point: 0
Off
Range: any FlexAnalog parameter
MESSAGE
Point: 1
Off
Range: any FlexAnalog parameter
↓
MESSAGE
Point: 255
Off
Range: any FlexAnalog parameter
 IEC 61850 PROTOCOL

 GSSE / GOOSE
 CONFIGURATION
MESSAGE
 SERVER
 CONFIGURATION
MESSAGE
 IEC 61850 LOGICAL
 NODE NAME PREFIXES
MESSAGE
 MMXU DEADBANDS

MESSAGE
 GGIO1 STATUS
 CONFIGURATION
MESSAGE
 GGIO2 CONTROL
 CONFIGURATION
MESSAGE
 GGIO4 ANALOG
 CONFIGURATION
MESSAGE
 GGIO5 UINTEGER
 CONFIGURATION
MESSAGE
 REPORT CONTROL
 CONFIGURATION
MESSAGE
 XCBR
 CONFIGURATION
MESSAGE
 XSWI
 CONFIGURATION
