5-134 G60 Generator Protection System GE Multilin
5.4 SYSTEM SETUP 5 SETTINGS
5
IEC61850-90-5 AGGREGATOR 1 CONFIGURATION
• PMU AGGREGATOR1: NAME: A user-defined visible string of characters (max. 56) to identify the source of the
stream. This value, concatenated with the Aggregator IDCode and Aggregator Class of Service, is mapped into the
IEC61850 MSVID filed in the output stream.
• AGGREGATOR1: PHYSICAL PORT: This setting determines which physical ports through which the synchrophasor
traffic will be transmitted. The range is 1, 2, 3.
• PMU AGGREGATOR1: UDP: This setting selects the UDP port number that is used by this dataset for network report-
ing. A default setting value for IEC 6150-90-5 is provided.
• PMU AGGREGATOR1: #OF ASDUs: This setting sets the number of ASDU’s per from 1 through to 4. Refer to the
table below.
m) CONTROL BLOCKS
PATH: SETTINGS  SYSTEM SETUP PHASOR MEASUREMENT UNIT IEC 90 – 5 MSVCB01 CONFIGURATION
• MSVCB 1 SVENA: The SV Stream Control is set by either toggling an assigned FlexLogic operand or a remote client
write, to start and stop the streaming of R-SV frames. If remote client control is disabled, a negative response is pro-
vided to the client in response to a write attempt. A FlexLogic operand (SvEna) is provided for each Aggregator that
Table 5–13: # OF ASDU
SETTINGS FOR # OF ASDU TRANSMISSION
1 ASDU at T0 (current values)
2 ASDU at T-1 (previous values) + ASDU at T0 (current values)
3 values)+ ASDU at T-2 (previous values) + ASDU at T-1 (previous ASDU at T0 (current
values)
4 ASDU at T-3 (previous values) + ASDU at T-2 (previous values) + ASDU at T-1 (previous
values)+ASDU at T0 (current values)
 IEC 90-5 MSVCB
 CONFIGURATION
MSVCB 1 SVENA:
OFF
Range: FlexLogic operand
MESSAGE
MSVCB 1 CLIENT CTRL:
OFF
Range: FlexLogic operand
MESSAGE
MSVCB 1 SVENA DEFLT:
OFF
Range: FlexLogic operand
MESSAGE
MSVCB 1 CONFREV:
1
Range: 1 to 4294967295
MESSAGE
MSVCB 1 PRIORITY:
4
Range: 0 to 7
MESSAGE
MSVCB 1 IP CLASS:
46
Range: 0 to 252
MESSAGE
MSVCB 1 VID:
0
Range: 0 to 4095
MESSAGE
MSVCB 1 APPID:
0
Range: 0 to 16383
MESSAGE
MSVCB 1 DEST. IP:
224.0.0.0
Range: 0 to 255.255.255.255
MESSAGE
MSVCB 1 SECURITY:
0
Range: 0 to 2
