5-312 G60 Generator Protection System GE Multilin
5.9 TRANSDUCER INPUTS AND OUTPUTS 5 SETTINGS
5
• RTD INPUT H1 TYPE: This setting specifies the RTD type. Four different RTD types are available: 100 Ω Nickel, 10 Ω
Copper, 100 Ω Platinum, and 120 Ω Nickel. Refer the table below for reference temperature values for each type.
• RTD INPUT H1 APPLICATION: This setting allows each individual RTD to be assigned to a group application. This is
useful for applications that require group measurement for voting. A value of “None” specifies that the RTD will operate
individually and not part of any RTD group. All RTDs programmed to “Stator” are used for RTD biasing of the G60 ther-
mal model. Common groups are provided for rotating machines applications such as ambient, bearing, group 1, or
group 2. If the
RTD INPUT H1 TRIP VOTING setting value is “Group”, then it is allowed to issue a trip if N –1 RTDs from the
same group also pick up, where N is the number of enabled RTDs from the group.
• RTD INPUT H1 ALARM TEMPERATURE: This setting specifies the temperature pickup level for the alarm stage.
• RTD INPUT H1 ALARM PKP DELAY: This setting specifies time delay for the alarm stage until the output can be
asserted.
• RTD INPUT H1 TRIP TEMPERATURE: This setting specifies the temperature pickup level for the trip stage.
• RTD INPUT H1 TRIP PKP DELAY: This setting specifies time delay for the trip stage until the output can be asserted.
Table 5–36: RTD TEMPERATURE VS. RESISTANCE
TEMPERATURE RESISTANCE (IN OHMS)
°C °F 100 OHM PT
(DIN 43760)
120 OHM NI 100 OHM NI 10 OHM CU
–50 –58 80.31 86.17 71.81 7.10
–40 –40 84.27 92.76 77.30 7.49
–30 –22 88.22 99.41 82.84 7.88
–20 –4 92.16 106.15 88.45 8.26
–10 14 96.09 113.00 94.17 8.65
0 32 100.00 120.00 100.00 9.04
10 50 103.90 127.17 105.97 9.42
20 68 107.79 134.52 112.10 9.81
30 86 111.67 142.06 118.38 10.19
40 104 115.54 149.79 124.82 10.58
50 122 119.39 157.74 131.45 10.97
60 140 123.24 165.90 138.25 11.35
70 158 127.07 174.25 145.20 11.74
80 176 130.89 182.84 152.37 12.12
90 194 134.70 191.64 159.70 12.51
100 212 138.50 200.64 167.20 12.90
110 230 142.29 209.85 174.87 13.28
120 248 146.06 219.29 182.75 13.67
130 266 149.82 228.96 190.80 14.06
140 284 153.58 238.85 199.04 14.44
150 302 157.32 248.95 207.45 14.83
160 320 161.04 259.30 216.08 15.22
170 338 164.76 269.91 224.92 15.61
180 356 168.47 280.77 233.97 16.00
190 374 172.46 291.96 243.30 16.39
200 392 175.84 303.46 252.88 16.78
210 410 179.51 315.31 262.76 17.17
220 428 183.17 327.54 272.94 17.56
230 446 186.82 340.14 283.45 17.95
240 464 190.45 353.14 294.28 18.34
250 482 194.08 366.53 305.44 18.73
