GE G60

2-26 G60 Generator Protection System GE Multilin
2.2 SPECIFICATIONS 2 PRODUCT DESCRIPTION
2
GPM-F-HM, GPM-F-L, GPM-F-R, GPM-S-B, AND GPM-S-G MODULE TYPE TESTS
TEST REFERENCE STANDARD TEST LEVEL
GPM-F TYPES GPM-S TYPES
Dielectric voltage withstand EN60255-5 2.3 kV AC / 4.6 kV DC 2.3 kV AC / 3.3 kV DC
Impulse voltage withstand EN60255-5 5 kV 5 kV
Insulation EN60255-5 500 V DC 500 V DC
Damped oscillatory IEC61000-4-18IEC60255-22-1 2.5 kV CM, 1 kV DM 2.5 kV CM, 1 kV DM
Electrostatic discharge EN61000-4-2/IEC60255-22-2 Level 4 Level 4
RF immunity EN61000-4-3/IEC60255-22-3 20 V/m 20 V/m
Fast Transient Disturbance EN61000-4-4/IEC60255-22-4 Class A and B Class A and B
Surge Immunity EN61000-4-5/IEC60255-22-5 Level 4 Level 4
Conducted RF Immunity EN61000-4-6/IEC60255-22-6 Level 3 Level 3
Voltage interruption and ripple DC IEC60255-11 15% ripple,
1 ms to 5 s interrupts
15% ripple,
1 ms to 5 s interrupts
Radiated and conducted emissions CISPR11 / CISPR22 / IEC60255-25 Class A Class A
Sinusoidal vibration IEC60255-21-1 Class 2 Class 1
Shock and Bump IEC60255-21-2 Class 2 Class 1
Seismic IEC60255-21-3 Class 2 Class 1
Power magnetic immunity IEC61000-4-8 Level 5 Level 5
Pulse magnetic immunity IEC61000-4-9 Level 4 Level 4
Damped magnetic immunity IEC61000-4-10 Level 4 Level 4
Voltage dip and interruption IEC61000-4-11 0%, 40%, 70%, 80% dips;
250/300 cycle interrupts
0%, 40%, 70%, 80% dips;
250/300 cycle interrupts
Voltage ripple IEC61000-4-17 15% ripple 15% ripple
Ingress protection IEC60529 IP10 IP10
Environmental (cold) IEC60068-2-1 –40°C, 16 hrs –40°C, 16 hrs
Environmental (dry heat) IEC60068-2-2 85°C, 16hrs 85°C, 16hrs
Relative humidity cyclic IEC60068-2-30 6 day, variant 1 6 day, variant 1
SWC oscillatory IEEE/ANSI C37.90.1 2.5 kV,1 MHz 2.5 kV,1 MHz
SWC transients IEEE/ANSI C37.90.1 4 kV 2.5 kHz 4 kV 2.5 kHz
RF immunity IEEE/ANSIC37.90.2 20 V/m 20 V/m
ESD IEEE/ANSIC37.90.3 15 kV air / 8 kV contact 15 kV air / 8 kV contact
Safety UL508 e83849 NKCR2 e83849 NKCR2
UL C22.2-14 e83849 NKCR8 e83849 NKCR8
