B.4 MEMORY MAPPING APPENDIX B
B
Passwords (Read Only)
4028 Command Password Status 0 to 1 --- 1 F102 0 (Disabled)
4029 Setting Password Status 0 to 1 --- 1 F102 0 (Disabled)
Passwords (Read/Write Setting)
402A Command Password Access Timeout 5 to 480 min 1 F001 5
402B Setting Password Access Timeout 5 to 480 min 1 F001 30
402C Invalid Password Attempts (before lockout) 2 to 5 --- 1 F001 3
402D Password Lockout Duration 5 to 60 min 1 F001 5
Passwords (Read/Write)
402E Password Access Events 0 to 1 --- 1 F102 0 (Disabled)
Passwords (Read/Write Setting)
402F Local Setting Auth 1 to 4294967295 --- 1 F300 1
4031 Remote Setting Auth 0 to 4294967295 --- 1 F300 1
4033 Access Auth Timeout 5 to 480 min 1 F001 30
User Display Invoke (Read/Write Setting)
4040 Invoke and Scroll Through User Display Menu Operand 0 to 4294967295 --- 1 F300 0
LED Test (Read/Write Setting)
4048 LED Test Function 0 to 1 --- 1 F102 0 (Disabled)
4049 LED Test Control 0 to 4294967295 --- 1 F300 0
Preferences (Read/Write Setting)
404F Language 0 to 4 --- 1 F531 0 (English)
4050 Flash Message Time 0.5 to 10 s 0.1 F001 10
4051 Default Message Timeout 10 to 900 s 1 F001 300
4052 Default Message Intensity 0 to 3 --- 1 F101 0 (25%)
4053 Screen Saver Feature 0 to 1 --- 1 F102 0 (Disabled)
4054 Screen Saver Wait Time 1 to 65535 min 1 F001 30
4055 Current Cutoff Level 0.002 to 0.02 pu 0.001 F001 20
4056 Voltage Cutoff Level 0.1 to 1 V 0.1 F001 10
Remote RTD Communications (Read/Write Setting)
407A RRTD Slave Address 1 to 254 --- 1 F001 254
407B RRTD Baud Rate 0 to 4 --- 1 F602 4 (19200)
Communications (Read/Write Setting)
407D COM2 Selection 0 to 3 --- 1 F601 0 (RS485)
407E COM1 Minimum Response Time 0 to 1000 ms 10 F001 0
407F COM2 Minimum Response Time 0 to 1000 ms 10 F001 0
4080 Modbus Slave Address 1 to 254 --- 1 F001 254
4083 RS485 Com1 Baud Rate 0 to 11 --- 1 F112 8 (115200)
4084 RS485 Com1 Parity 0 to 2 --- 1 F113 0 (None)
4085 RS485 Com2 Baud Rate 0 to 11 --- 1 F112 8 (115200)
4086 RS485 Com2 Parity 0 to 2 --- 1 F113 0 (None)
4087 Port 1 IP Address 0 to 4294967295 --- 1 F003 2130706433
4089 Port 1 IP Subnet Mask 0 to 4294967295 --- 1 F003 4294966272
408B Port 1 Gateway IP Address 0 to 4294967295 --- 1 F003 56554497
408D Network Address NSAP --- --- --- F074 0
4097 Port 1 Link Loss Alert 0 to 1 --- 1 F102 0 (Disabled)
4098 Port 2 Link Loss Alert 0 to 1 --- 1 F102 0 (Disabled)
4099 Port 3 Link Loss Alert 0 to 1 --- 1 F102 0 (Disabled)
409A DNP Channel 1 Port 0 to 5 --- 1 F177 0 (None)
409B DNP Channel 2 Port 0 to 5 --- 1 F177 0 (None)
409C DNP Address 0 to 65519 --- 1 F001 1
409E DNP Client Addresses (2 items) 0 to 4294967295 --- 1 F003 0
40A3 TCP Port Number for the Modbus Protocol 0 to 65535 --- 1 F001 502
40A4 TCP/UDP Port Number for the DNP Protocol 0 to 65535 --- 1 F001 20000
40A5 TCP Port Number for the HTTP (Web Server) Protocol 0 to 65535 --- 1 F001 80
Table B–10: MODBUS MEMORY MAP (Sheet 18 of 68)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
