B-46 G60 Generator Protection System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
7A87 Underfrequency 1 Source 0 to 5 --- 1 F167 0 (SRC 1)
7A88 Underfrequency 1 Events 0 to 1 --- 1 F102 0 (Disabled)
7A89 Underfrequency 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
7A8A Underfrequency 1 Reserved (5 items) 0 to 1 --- 1 F001 0
7A8F ...Repeated for Underfrequency 2
7A9E ...Repeated for Underfrequency 3
7AAD ...Repeated for Underfrequency 4
7ABC ...Repeated for Underfrequency 5
7ACB ...Repeated for Underfrequency 6
User Programmable Pushbuttons (Read/Write Setting) (16 modules)
7B60 User Programmable Pushbutton 1 Function 0 to 2 --- 1 F137 0 (Disabled)
7B61 User Programmable Pushbutton 1 Top Line --- --- --- F202 (none)
7B6B User Programmable Pushbutton 1 On Text --- --- --- F202 (none)
7B75 User Programmable Pushbutton 1 Off Text --- --- --- F202 (none)
7B7F User Programmable Pushbutton 1 Drop-Out Time 0 to 60 s 0.05 F001 0
7B80 User Programmable Pushbutton 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
7B81 User Programmable Pushbutton 1 Events 0 to 1 --- 1 F102 0 (Disabled)
7B82 User Programmable Pushbutton 1 LED Operand 0 to 4294967295 --- 1 F300 0
7B84 User Programmable Pushbutton 1 Autoreset Delay 0.2 to 600 s 0.1 F001 10
7B85 User Programmable Pushbutton 1 Autoreset Function 0 to 1 --- 1 F102 0 (Disabled)
7B86 User Programmable Pushbutton 1 Local Lock Operand 0 to 4294967295 --- 1 F300 0
7B88 User Programmable Pushbutton 1 Message Priority 0 to 2 --- 1 F220 0 (Disabled)
7B89 User Programmable Pushbutton 1 Remote Lock Operand 0 to 4294967295 --- 1 F300 0
7B8B User Programmable Pushbutton 1 Reset Operand 0 to 4294967295 --- 1 F300 0
7B8D User Programmable Pushbutton 1 Set Operand 0 to 4294967295 --- 1 F300 0
7B8F User Programmable Pushbutton 1 Hold 0 to 10 s 0.1 F001 1
7B90 ...Repeated for User Programmable Pushbutton 2
7BC0 ...Repeated for User Programmable Pushbutton 3
7BF0 ...Repeated for User Programmable Pushbutton 4
7C20 ...Repeated for User Programmable Pushbutton 5
7C50 ...Repeated for User Programmable Pushbutton 6
7C80 ...Repeated for User Programmable Pushbutton 7
7CB0 ...Repeated for User Programmable Pushbutton 8
7CE0 ...Repeated for User Programmable Pushbutton 9
7D10 ...Repeated for User Programmable Pushbutton 10
7D40 ...Repeated for User Programmable Pushbutton 11
7D70 ...Repeated for User Programmable Pushbutton 12
7DA0 ...Repeated for User Programmable Pushbutton 13
7DD0 ...Repeated for User Programmable Pushbutton 14
7E00 ...Repeated for User Programmable Pushbutton 15
7E30 ...Repeated for User Programmable Pushbutton 16
Neutral Overvoltage (Read/Write Grouped Setting) (3 modules)
7F00 Neutral Overvoltage 1 Function 0 to 1 --- 1 F102 0 (Disabled)
7F01 Neutral Overvoltage 1 Signal Source 0 to 5 --- 1 F167 0 (SRC 1)
7F02 Neutral Overvoltage 1 Pickup 0 to 3 pu 0.001 F001 300
7F03 Neutral Overvoltage 1 Pickup Delay 0 to 600 s 0.01 F001 100
7F04 Neutral Overvoltage 1 Reset Delay 0 to 600 s 0.01 F001 100
7F05 Neutral Overvoltage 1 Block 0 to 4294967295 --- 1 F300 0
7F07 Neutral Overvoltage 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
7F08 Neutral Overvoltage 1 Events 0 to 1 --- 1 F102 0 (Disabled)
7F09 Neutral Overvoltage 1 Curves 0 to 3 --- 1 F116 0 (Definite Time)
7F0A Reserved (8 items) 0 to 65535 --- 1 F001 0
7F11 ...Repeated for Neutral Overvoltage 2
7F22 ...Repeated for Neutral Overvoltage 3
Table B–10: MODBUS MEMORY MAP (Sheet 38 of 68)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
