GE G60 - Page 651

GE Multilin G60 Generator Protection System B-57
APPENDIX B B.4 MEMORY MAPPING
B
AB0B ...Repeated for Module 2
AB16 ...Repeated for Module 3
AB21 ...Repeated for Module 4
AB2C ...Repeated for Module 5
AB37 ...Repeated for Module 6
IEC 61850 LN Name Prefixes (Read/Write Settings)
AB48 IEC 61850 Logical Node LPHD1 Name Prefix 0 to 65534 --- 1 F206 (none)
AB4B IEC 61850 Logical Node PIOCx Name Prefix (72 items) 0 to 65534 --- 1 F206 (none)
AC23 IEC 61850 Logical Node PTOCx Name Prefix (24 items) 0 to 65534 --- 1 F206 (none)
AC6B IEC 61850 Logical Node PTUVx Name Prefix (13 items) 0 to 65534 --- 1 F206 (none)
AC92 IEC 61850 Logical Node PTOVx Name Prefix (10 items) 0 to 65534 --- 1 F206 (none)
ACB0 IEC 61850 Logical Node PDISx Name Prefix (10 items) 0 to 65534 --- 1 F206 (none)
ACCE IEC 61850 Logical Node RBRFx Name Prefix (24 items) 0 to 65534 --- 1 F206 (none)
AD16 IEC 61850 Logical Node RPSBx Name Prefix 0 to 65534 --- 1 F206 (none)
AD19 IEC 61850 Logical Node RRECx Name Prefix (6 items) 0 to 65534 --- 1 F206 (none)
AD2B IEC 61850 Logical Node MMXUx Name Prefix (6 items) 0 to 65534 --- 1 F206 (none)
AD3D IEC 61850 Logical Node GGIOx Name Prefix (5 items) 0 to 65534 --- 1 F206 (none)
AD4C IEC 61850 Logical Node RFLOx Name Prefix (5 items) 0 to 65534 --- 1 F206 (none)
AD5B IEC 61850 Logical Node XCBRx Name Prefix (6 items) 0 to 65534 --- 1 F206 (none)
AD6D IEC 61850 Logical Node PTRCx Name Prefix (6 items) 0 to 65534 --- 1 F206 (none)
AD7F IEC 61850 Logical Node PDIFx Name Prefix (4 items) 0 to 65534 --- 1 F206 (none)
AD8B IEC 61850 Logical Node MMXNx Name Prefix (37 items) 0 to 65534 --- 1 F206 (none)
ADFA IEC 61850 Logical Node CSWIx Name Prefix (30 items) 0 to 65534 --- 1 F206 (none)
AE54 IEC 61850 Logical Node XSWIx Name Prefix (24 items) 0 to 65534 --- 1 F206 (none)
IEC 61850 GGIO4 General Analog Configuration Settings (Read/Write Setting)
AF00 Number of Analog Input Points in GGIO4 4 to 32 --- 4 F001 4
IEC 61850 GGIO4 Analog Input Points Configuration Settings (Read/Write Setting) (32 modules)
AF10 IEC 61850 GGIO4 Analog Input 1 Value --- --- --- F600 0
AF11 IEC 61850 GGIO4 Analog Input 1 Deadband 0.001 to 100 % 0.001 F003 100000
AF13 IEC 61850 GGIO4 Analog Input 1 Minimum –1000000000000 to
1000000000000
--- 0.001 F060 0
AF15 IEC 61850 GGIO4 Analog Input 1 Maximum –1000000000000 to
1000000000000
--- 0.001 F060 1000000
AF17 ...Repeated for IEC 61850 GGIO4 Analog Input 2
AF1E ...Repeated for IEC 61850 GGIO4 Analog Input 3
AF25 ...Repeated for IEC 61850 GGIO4 Analog Input 4
AF2C ...Repeated for IEC 61850 GGIO4 Analog Input 5
AF33 ...Repeated for IEC 61850 GGIO4 Analog Input 6
AF3A ...Repeated for IEC 61850 GGIO4 Analog Input 7
AF41 ...Repeated for IEC 61850 GGIO4 Analog Input 8
AF48 ...Repeated for IEC 61850 GGIO4 Analog Input 9
AF4F ...Repeated for IEC 61850 GGIO4 Analog Input 10
AF56 ...Repeated for IEC 61850 GGIO4 Analog Input 11
AF5D ...Repeated for IEC 61850 GGIO4 Analog Input 12
AF64 ...Repeated for IEC 61850 GGIO4 Analog Input 13
AF6B ...Repeated for IEC 61850 GGIO4 Analog Input 14
AF72 ...Repeated for IEC 61850 GGIO4 Analog Input 15
AF79 ...Repeated for IEC 61850 GGIO4 Analog Input 16
AF80 ...Repeated for IEC 61850 GGIO4 Analog Input 17
AF87 ...Repeated for IEC 61850 GGIO4 Analog Input 18
AF8E ...Repeated for IEC 61850 GGIO4 Analog Input 19
AF95 ...Repeated for IEC 61850 GGIO4 Analog Input 20
AF9C ...Repeated for IEC 61850 GGIO4 Analog Input 21
AFA3 ...Repeated for IEC 61850 GGIO4 Analog Input 22
Table B–10: MODBUS MEMORY MAP (Sheet 49 of 68)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
