GE Multilin G60 Generator Protection System B-59
APPENDIX B B.4 MEMORY MAPPING
B
B0E8 IEC 61850 MMXU VAr.phsC Deadband 1 0.001 to 100 % 0.001 F003 10000
B0EA IEC 61850 MMXU VA.phsA Deadband 1 0.001 to 100 % 0.001 F003 10000
B0EC IEC 61850 MMXU VA.phsB Deadband 1 0.001 to 100 % 0.001 F003 10000
B0EE IEC 61850 MMXU VA.phsC Deadband 1 0.001 to 100 % 0.001 F003 10000
B0F0 IEC 61850 MMXU PF.phsA Deadband 1 0.001 to 100 % 0.001 F003 10000
B0F2 IEC 61850 MMXU PF.phsB Deadband 1 0.001 to 100 % 0.001 F003 10000
B0F4 IEC 61850 MMXU PF.phsC Deadband 1 0.001 to 100 % 0.001 F003 10000
B0F6 ...Repeated for Deadband 2
B12C ...Repeated for Deadband 3
B162 ...Repeated for Deadband 4
B198 ...Repeated for Deadband 5
B1CE ...Repeated for Deadband 6
IEC 61850 Received Analogs (Read Only) (32 modules)
B210 IEC 61850 Received Analog 1 -1000000000000 to
1000000000000
--- 0.001 F060 0
B212 ...Repeated for Received Analog 2
B214 ...Repeated for Received Analog 3
B216 ...Repeated for Received Analog 4
B218 ...Repeated for Received Analog 5
B21A ...Repeated for Received Analog 6
B21C ...Repeated for Received Analog 7
B21E ...Repeated for Received Analog 8
B220 ...Repeated for Received Analog 9
B222 ...Repeated for Received Analog 10
B224 ...Repeated for Received Analog 11
B226 ...Repeated for Received Analog 12
B228 ...Repeated for Received Analog 13
B22A ...Repeated for Received Analog 14
B22C ...Repeated for Received Analog 15
B22E ...Repeated for Received Analog 16
B230 ...Repeated for Received Analog 17
B232 ...Repeated for Received Analog 18
B234 ...Repeated for Received Analog 19
B236 ...Repeated for Received Analog 20
B238 ...Repeated for Received Analog 21
B23A ...Repeated for Received Analog 22
B23C ...Repeated for Received Analog 23
B23E ...Repeated for Received Analog 24
B240 ...Repeated for Received Analog 25
B242 ...Repeated for Received Analog 26
B244 ...Repeated for Received Analog 27
B246 ...Repeated for Received Analog 28
B248 ...Repeated for Received Analog 29
B24A ...Repeated for Received Analog 30
B24C ...Repeated for Received Analog 31
B24E ...Repeated for Received Analog 32
IEC 61850 Configurable Report Settings (Read/Write Setting)
B290 IEC 61850 Configurable Reports Dataset Items (64 items) 0 to 848 --- 1 F615 0 (None)
IEC 61850 XSWI Configuration (Read/Write Setting) (24 modules)
B370 FlexLogic Operand for IEC 61850 XSWI.ST.Loc Status 0 to 4294967295 --- 1 F300 0
B373 ...Repeated for module number 2
B376 ...Repeated for module number 3
B379 ...Repeated for module number 4
B37C ...Repeated for module number 5
Table B–10: MODBUS MEMORY MAP (Sheet 51 of 68)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
