GE G60

B-72 G60 Generator Protection System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
D351 IEC 61850 GGIO2.CF.SPCSO50.ctlModel Value 0 to 2 --- 1 F001 1
D352 IEC 61850 GGIO2.CF.SPCSO51.ctlModel Value 0 to 2 --- 1 F001 1
D353 IEC 61850 GGIO2.CF.SPCSO52.ctlModel Value 0 to 2 --- 1 F001 1
D354 IEC 61850 GGIO2.CF.SPCSO53.ctlModel Value 0 to 2 --- 1 F001 1
D355 IEC 61850 GGIO2.CF.SPCSO54.ctlModel Value 0 to 2 --- 1 F001 1
D356 IEC 61850 GGIO2.CF.SPCSO55.ctlModel Value 0 to 2 --- 1 F001 1
D357 IEC 61850 GGIO2.CF.SPCSO56.ctlModel Value 0 to 2 --- 1 F001 1
D358 IEC 61850 GGIO2.CF.SPCSO57.ctlModel Value 0 to 2 --- 1 F001 1
D359 IEC 61850 GGIO2.CF.SPCSO58.ctlModel Value 0 to 2 --- 1 F001 1
D35A IEC 61850 GGIO2.CF.SPCSO59.ctlModel Value 0 to 2 --- 1 F001 1
D35B IEC 61850 GGIO2.CF.SPCSO60.ctlModel Value 0 to 2 --- 1 F001 1
D35C IEC 61850 GGIO2.CF.SPCSO61.ctlModel Value 0 to 2 --- 1 F001 1
D35D IEC 61850 GGIO2.CF.SPCSO62.ctlModel Value 0 to 2 --- 1 F001 1
D35E IEC 61850 GGIO2.CF.SPCSO63.ctlModel Value 0 to 2 --- 1 F001 1
D35F IEC 61850 GGIO2.CF.SPCSO64.ctlModel Value 0 to 2 --- 1 F001 1
Remote Device Status (Read Only) (16 modules)
D380 Remote Device 1 StNum 0 to 4294967295 --- 1 F003 0
D382 Remote Device 1 SqNum 0 to 4294967295 --- 1 F003 0
D384 ...Repeated for Remote Device 2
D388 ...Repeated for Remote Device 3
D38C ...Repeated for Remote Device 4
D390 ...Repeated for Remote Device 5
D394 ...Repeated for Remote Device 6
D398 ...Repeated for Remote Device 7
D39C ...Repeated for Remote Device 8
D3A0 ...Repeated for Remote Device 9
D3A4 ...Repeated for Remote Device 10
D3A8 ...Repeated for Remote Device 11
D3AC ...Repeated for Remote Device 12
D3B0 ...Repeated for Remote Device 13
D3B4 ...Repeated for Remote Device 14
D3B8 ...Repeated for Remote Device 15
D3BC ...Repeated for Remote Device 16
Phasor Measurement Unit Basic Configuration (Read/Write Setting)
D400 PMU 1 Function 0 to 1 --- 1 F102 0 (Disabled)
D401 PMU 1 LDInst --- --- --- F214 "PMUx"
D422 PMU 1 IDcode 1 to 65534 --- 1 F001 1
D423 PMU 1 STN --- --- --- F203 "GE-UR-PMU"
D42B PMU 1 Source 0 to 5 --- 1 F167 0 (SRC 1)
D42C PMU 1 Class 0 to 2 --- 1 F549 1 (M-CLASS)
D42D PMU 1 Format 0 to 1 --- 1 F547 0 (Integer)
D42E PMU 1 Style 0 to 1 --- 1 F546 0 (Polar)
D42F PMU 1 Rate 0 to 13 --- 1 F544 4 (10/sec)
D430 PMU 1 PHS-x (14 items) 0 to 14 --- 1 F543 1 (Va)
D43E PMU 1 PHS-x Name (14 items) --- --- --- F203 "GE-UR-PMU-
PHS 1 "
D4AE PMU 1 A-CH-x (16 items) 0 to 65535 --- 1 F600 0
D4BE PMU 1 A-CH-x (16 items) --- --- --- F203 "AnalogChannel 1
"
D53E PMU 1 D-CH-x (16 items) 0 to 4294967295 --- 1 F300 0
D55E PMU 1 D-CH-x Name (16 items) --- --- --- F203 "Dig Channel 1 "
D5DE PMU 1 D-CH-x Normal State (16 items) 0 to 1 --- 1 F108 0 (Off)
D5EE PMU 1 Reserved (17 items) 0 to 1 --- 1 F001 0
Contact Outputs (Read/Write Setting) (64 modules)
DC90 Contact Output 1 Name --- --- --- F205 “Cont Op 1"
Table B–10: MODBUS MEMORY MAP (Sheet 64 of 68)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
