B-78 G60 Generator Protection System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
F102
ENUMERATION: DISABLED/ENABLED
0 = Disabled, 1 = Enabled
F103
ENUMERATION: CURVE SHAPES
F104
ENUMERATION: RESET TYPE
0 = Instantaneous, 1 = Timed
F106
ENUMERATION: PHASE ROTATION
0 = ABC, 1 = ACB
F108
ENUMERATION: OFF/ON
0 = Off, 1 = On
F109
ENUMERATION: CONTACT OUTPUT OPERATION
0 = Self-reset, 1 = Latched, 2 = Disabled
F111
ENUMERATION: UNDERVOLTAGE CURVE SHAPES
0 = Definite Time, 1 = Inverse Time
F112
ENUMERATION: RS485 BAUD RATES
F113
ENUMERATION: PARITY
0 = None, 1 = Odd, 2 = Even
F114
ENUMERATION: IRIG-B SIGNAL TYPE
0 = None, 1 = DC Shift, 2 = Amplitude Modulated
F116
ENUMERATION: NEUTRAL OVERVOLTAGE CURVES
0 = Definite Time, 1 = FlexCurve A, 2 = FlexCurve B,
3 = FlexCurve C
F118
ENUMERATION: OSCILLOGRAPHY MODE
0 = Automatic Overwrite, 1 = Protected
F119
ENUMERATION: FLEXCURVE PICKUP RATIOS
Bitmask Curve shape Bitmask Curve shape
0 IEEE Mod Inv 9 IAC Inverse
1 IEEE Very Inv 10 IAC Short Inv
2 IEEE Ext Inv 11 I2t
3 IEC Curve A 12 Definite Time
4 IEC Curve B 13 FlexCurve A
5 IEC Curve C 14 FlexCurve B
6 IEC Short Inv 15 FlexCurve C
7 IAC Ext Inv 16 FlexCurve D
8IAC Very Inv
Bitmask Value Bitmask Value Bitmask Value
0 300 4 9600 8 115200
1 1200 5 19200 9 14400
2 2400 6 38400 10 28800
3 4800 7 57600 11 33600
Mask Value Mask Value Mask Value Mask Value
00.00300.88602.90905.90
10.05310.90613.00916.00
20.10320.91623.10926.50
30.15330.92633.20937.00
40.20340.93643.30947.50
50.25350.94653.40958.00
60.30360.95663.50968.50
70.35370.96673.60979.00
80.40380.97683.70989.50
90.45390.98693.809910.00
10 0.48 40 1.03 70 3.90 100 10.50
11 0.50 41 1.05 71 4.00 101 11.00
12 0.52 42 1.10 72 4.10 102 11.50
13 0.54 43 1.20 73 4.20 103 12.00
14 0.56 44 1.30 74 4.30 104 12.50
15 0.58 45 1.40 75 4.40 105 13.00
16 0.60 46 1.50 76 4.50 106 13.50
17 0.62 47 1.60 77 4.60 107 14.00
18 0.64 48 1.70 78 4.70 108 14.50
19 0.66 49 1.80 79 4.80 109 15.00
20 0.68 50 1.90 80 4.90 110 15.50
21 0.70 51 2.00 81 5.00 111 16.00
22 0.72 52 2.10 82 5.10 112 16.50
23 0.74 53 2.20 83 5.20 113 17.00
24 0.76 54 2.30 84 5.30 114 17.50
25 0.78 55 2.40 85 5.40 115 18.00
26 0.80 56 2.50 86 5.50 116 18.50
27 0.82 57 2.60 87 5.60 117 19.00
28 0.84 58 2.70 88 5.70 118 19.50
29 0.86 59 2.80 89 5.80 119 20.00
