GE Multilin G60 Generator Protection System B-83
APPENDIX B B.4 MEMORY MAPPING
B
F143
UR_UINT32: 32 BIT ERROR CODE (F141 specifies bit number)
A bit value of 0 = no error, 1 = error
F144
ENUMERATION: FORCED CONTACT INPUT STATE
0 = Disabled, 1 = Open, 2 = Closed
F146
ENUMERATION: MISCELLANEOUS EVENT CAUSES
F151
ENUMERATION: RTD SELECTION
F152
ENUMERATION: SETTING GROUP
0 = Active Group, 1 = Group 1, 2 = Group 2, 3 = Group 3
4 = Group 4, 5 = Group 5, 6 = Group 6
81 Module Failure 08
82 Module Failure 09
83 Incompatible H/W
84 Module Failure 10
85 Module Failure 11
86 Module Failure 12
87 High ENET Traffic
89 Relay Restart
90 FGM Failure
91 FGM Failure
92 FGM Failure
93 FGM Failure
94 FGM Failure
95 FGM Error
96 Maintenance Alert
97 PHY Monitor
98 Storage Media Alarm
99 Wrong Transceiver
Bitmask Definition
0 Events Cleared
1 Oscillography Triggered
2 Date/time Changed
3 Default Settings Loaded
4 Test Mode Forcing On
5 Test Mode Forcing Off
6 Power On
7 Power Off
8 Relay In Service
9 Relay Out Of Service
10 Watchdog Reset
11 Oscillography Clear
12 Reboot Command
13 Led Test Initiated
14 Flash Programming
Bitmask Error
15 Fault Report Trigger
16 User Programmable Fault Report Trigger
17 ---
18 Reload CT/VT module Settings
19 ---
20 Ethernet Port 1 Offline
21 Ethernet Port 2 Offline
22 Ethernet Port 3 Offline
23 Ethernet Port 4 Offline
24 Ethernet Port 5 Offline
25 Ethernet Port 6 Offline
26 Test Mode Isolated
27 Test Mode Forcible
28 Test Mode Disabled
29 Temperature Warning On
30 Temperature Warning Off
31 Unauthorized Access
32 System Integrity Recovery
33 System Integrity Recovery 06
34 System Integrity Recovery 07
Bitmask RTD# Bitmask RTD# Bitmask RTD#
0 NONE 17 RTD 17 33 RTD 33
1 RTD 1 18 RTD 18 34 RTD 34
2 RTD 2 19 RTD 19 35 RTD 35
3 RTD 3 20 RTD 20 36 RTD 36
4 RTD 4 21 RTD 21 37 RTD 37
5 RTD 5 22 RTD 22 38 RTD 38
6 RTD 6 23 RTD 23 39 RTD 39
7 RTD 7 24 RTD 24 40 RTD 40
8 RTD 8 25 RTD 25 41 RTD 41
9 RTD 9 26 RTD 26 42 RTD 42
10 RTD 10 27 RTD 27 43 RTD 43
11 RTD 11 28 RTD 28 44 RTD 44
12 RTD 12 29 RTD 29 45 RTD 45
13 RTD 13 30 RTD 30 46 RTD 46
14 RTD 14 31 RTD 31 47 RTD 47
15 RTD 15 32 RTD 32 48 RTD 48
16 RTD 16
Bitmask Definition
