B-94 G60 Generator Protection System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
F544
ENUMERATION: PMU RECORDING/REPORTING RATE
F546
ENUMERATION: PMU REPORTING STYLE
0 = Polar, 1 = Rectangular
F547
ENUMERATION: PMU REPORTING FORMAT
0 = Integer, 1 = Floating
F548
ENUMERATION: PMU COM PROTOCOL
0 = NONE, 1 = 37.118, 2 = 61850-90-5
F549
ENUMERATION: PMU PERFORMANCE CLASS
0 = None, 1 = M-CLASS, 2 = P-CLASS
F550
ENUMERATION: RTD INPUT APPLICATION
F551
ENUMERATION: RTD TRIP VOTING
F552
ENUMERATION: RTD INPUT OPEN
F563
ENUMERATION: DSCP TYPE
F600
UR_UINT16: FLEXANALOG PARAMETER
Corresponds to the Modbus address of the value used when this
parameter is selected. Only certain values can be used as FlexAn-
alogs (basically all metering quantities used in protection).
F601
ENUMERATION: COM2 PORT USAGE
F602
ENUMERATION: RRTD BAUD RATE
Value Rate Value Rate
0 1/second 7 20second
1 2/second 8 25/second
2 4/second 9 30/second
3 5/second 10 50/second
4 10/second 11 60/second
5 12/second 12 100/second
6 15/second 13 120/second
Enumeration RTD input application
0None
1Stator
2 Bearing
3Ambient
4Group 1
5Group 2
Enumeration RTD trip voting
0None
1Group
2 RTD Input 1
3 RTD Input 2
4 RTD Input 3
5 RTD Input 4
6 RTD Input 5
7 RTD Input 6
8 RTD Input 7
9 RTD Input 8
10 RTD Input 9
11 RTD Input 10
12 RTD Input 11
13 RTD Input 12
Enumeration RTD open
0None
1Alarm
2Block
Enumeration DSCP type
0None
1 Expedited Forwarding
Enumeration COM2 port usage
0 RS485
1RRTD
2 GPM-F
3 RRTD and GPM-F
Enumeration RRTD baud rate
0 1200 bps
1 2400 bps
2 4800 bps
3 9600 bps
4 19200 bps
Enumeration RTD trip voting
