GE GTDS855GDMC - Table of Contents

3
Copyright General Electric 2012
12/3/2012
Table of Contents
Page Number ……………………………………......Description
3, 4, 5 ………………………………………………………..Table Of Contents
6, 7, 8, 9 …………………………………………………...Safety
10 ………..……………………………………………………Nomenclature
11 ……………………………………………………………..Mini Manual location
12, 13 ……………………………………………………….Warranty Info
14 ……………………………………………………………..Schematic, Electric Dryer - AC Voltage Into The Board and
Motor Switch
15 ……………………………………………………………..Schematic Gas Dryer - AC Voltage To The Board
16 ……………………………………………………………..Schematic, Electric And Gas – Long Vent
17 ……………………………………………………………..Schematic, Electric And Gas – Mist Water Valve
18, 19, 20, 21 …………………………………………..Service Mode
22, 23 ,24 …………………………………………………Resistance/Voltage Charts
25 ……………………………………………………………..Main Board Connecter Locations
26 ……………………………………………………………..Diagnostics From The Board - Sensor Rods
27 ……………………………………………………………..Diagnostics From The Board - LED Light
28 ……………………………………………………………..Diagnostics From The Board - Inlet Thermistor
29 ……………………………………………………………..Diagnostics From The Board - Outlet Thermistor
30 ……………………………………………………………..Diagnostics From The Board - Heaters Resistance Reading
31 ……………………………………………………………..Diagnostics From The Board - Heaters Voltage Reading / Low
Heat or No Heat Issues
