To remove heater assembly, make sure
power cord or circuit breaker is locked
out with LOTO, disconnect the power
wires. TAKE NOTE OF WIRE COLOR
POSITIONS FOR REINSTALATION.
Then remove the 2- ¼ inch
hex head screws at the front
of the heater and the screw at
the top rear of the heater
housing.
Heater Removal - Electric
