Above diagram shows only non long vent and non steam models.
Diagnostics From The Board
Sensor Rods
Check from the J25 connecter on the board. Look for approximately 5 VDC. Lay a wet cloth
across the rods in the drum. You should see the voltage drop.
If you do not see the voltage drop, disconnect power from the dryer. Disconnect the J25
connecter from the board. With the wet cloth still across the rods, check the continuity across
the pink and gray wires. If no continuity, visually check harness and connecters for damage.
If you have continuity, replace board.
