GE GTDS855GDMC - Page 4

5
Copyright General Electric 2012
12/3/2012
Table of Contents
Page Number ……………………………………......Description
71 ……………………………………………………………. Disassembly – Internal Components – Electric
72 ……………………………………………………………. Disassembly – Internal Components Electric - Thermistor/
Thermostat Locations
73 ……………………………………………………………. Disassembly – Internal Components Gas
74 ……………………………………………………………. Disassembly – Internal Components Gas - Thermistor/
Thermostat Locations
75 ……………………………………………………………. Rear Roller Support Bulkhead - Removal
76 ……………………………………………………………. Blower
77 ……………………………………………………………. Heater Removal – Electric
78 ……………………………………………………………. Heater Removal – Gas
79 ……………………………………………………………. Heater Removal – Gas Valve Assembly
80 ……………………………………………………………. Heater Removal – Main Burner Assembly
81, 82 ……………………………………………………… Heater Removal – Glow Bar Replacement
83 …………………………………………………………... Flame sensor - Removal
84, 85 …….……………………………………………….. Water Valve
86 - 90 ……………………………………………………. Before You Call For Service
91 ……………………………………………………………. Any Questions - End
