Bottom of Subwasher
Platform Assembly Installation
Install the platform starting
with the inner bolts first.
They are numbered 1,2,3
and 4. Start with number 1
first.
Start the bolts but do not
tighten all the way in right
away. Tighten each bolt ¼ of
the way in at a time. This is
done to pull the pressed on
seal into the tub assembly
evenly.
4
3
2
1
Once the inner bolts are all
pulled in, the outer bolts
may then be installed.
Tighten and torque to 65
inch lbs.
