DIAGNOSTIC STATUS CODES
SX TRANSISTOR CONTROL Page 48
September 2004
TRACTION
STATUS CODE
DESCRIPTION OF STATUS CAUSE OF STATUS INDICATION
-99
Maintenance alert and speed limit. This status code will be displayed when the “normal”
hour meter exceeds the “maintenance alert hours”
setting for the vehicle.
MEMORY RECALL
YES
CORRECTIVE ACTIONS TROUBLE-SHOOTING DIAGRAM
Circuits valid
for
Traction
Controller
SYMPTOM
Status code is displayed for 4 seconds when the
key switch is first turned on, and/or the vehicle
may run at a reduced speed.
CUSTOMER SELECTED SETTING WITH THE
HANDSET:
User defined status code is displayed when the
normal hour meter reading exceeds the
programmed “maintenance alert hours” setting
selected by the user
• Maintenance Code Hour Meter, Functions 19
and 20, are programmed with the Handset and
command the display of status code -99.
• If desired, Maintenance Code Speed Limit,
Function 13, can be programmed with the
Handset.
User should perform the desired maintenance
function. Re-set maintenance alert hour meter
after maintenance is performed.
NO DIAGRAM
USER SHOULD PERFORM THE DESIRED
MAINTENANCE FUNCTION
