GE IC3645SR4W606MC2 User Manual

RS-232 MEMORY MAP TABLES
SX TRANSISTOR CONTROL Page 75
Section 9.0 MEMORY MAPS
Section 9.1 Traction Control
September 2004
E
2
Func No. HS
No.
Traction Control
Function
Access By Restrictions
0 1 1 Motor EMF Required for Plug/Regen HS or PC None
1 2 2 Creep HS or PC None
2 3 3 Controlled Acceleration HS or PC None
3 4 4 Armature Current Limit HS or PC None
4 5 5 Counter EMF Trip Point for Auto Braking HS or PC None
5 6 6 Auto Calibration of Accelerator Pot HS or PC None
6 7 7 Minimum Field Current HS or PC None
7 8 8 Maximum Field Current HS or PC None
8 9 9 Regen Current Limit HS or PC None
9 10 10 Field Current for Regen HS or PC None
10 11 11 Brake Switch Current Limit HS or PC None
11 12 12 Top Speed Limit HS or PC None
12 13 13 Maintenance & Truck Mgmt Speed Limit HS or PC None
13 14 14 IR Compensation HS or PC None
14 15 15 Battery Volts Select HS or PC None
15 16 16 Stall Protection and % ON-Time Trip HS or PC None
16 17 17 Card Type Select HS or PC None
17 18 18 Steer Pump Time Delay HS or PC None
18 19 19 Maintenance Code HM (Tens/Units) HS or PC None
19 20 20 Maintenance Code HM (Thou/Hun) HS or PC None
20 21 21 Auto Regen Braking Current Limit HS or PC None
21 22 22 Mode Storage HS or PC For DD on power up
22 23 23 Regen Cancel Current HS or PC None
23 24 24 FW Start HS or PC None
24 25 25 Monitor HS or PC GE Temporary Storage
25 26 26 Ratio HS or PC GE Temporary Storage
26 27 27 Steer Pump Minutes HS or PC GE Temporary Storage
27 28 28 Fault Count Pointer HS or PC None
28 29 29 Steer Pump Hours (Tens/Ones) HS or PC None
29 30 30 Steer Pump Hours (Thou/Hun) HS or PC None
30 31 Traction Hours (Tens/Ones) PC Only None
31 32 Traction Hours (Thou/Hun) PC Only None
32 33
(18)
Stored Status Code #1 PC Only Reset to Zero Only
33 34 BDI 1 PC Only Reset to Zero Only
34 35 Hours (Tens/Ones) 1 PC Only Reset to Zero Only
35 36 Hours (Thou/Hun) 1 PC Only Reset to Zero Only
36 37
(20)
Stored Status Code #2 PC Only Reset to Zero Only
37 38 BDI 2 PC Only Reset to Zero Only
38 39 Hours (Tens/Ones) 2 PC Only Reset to Zero Only
39 40 Hours (Thou/Hun) 2 PC Only Reset to Zero Only
40 41
(22)
Stored Status Code #3 PC Only Reset to Zero Only
41 42 BDI 3 PC Only Reset to Zero Only
42 43 Hours (Tens/Ones) 3 PC Only Reset to Zero Only
