INSTALLATION INSTRUCTIONS
Installation Instructions
5
INSTALL THE ICEMAKER FILL CUP
Ŷ ,QVWDOOWKHLFHPDNHUILOOFXSVLGHPRXQWHG
into the icemaker as shown.
8
INSTALL THE ICE BUCKET
Ŷ Put the ice bucket LQSODFHXQGHUWKH
icemaker.
Ŷ Make sure the icemaker
power switch is set to
OFF.
10
KEEP THIS MANUAL
Ŷ The warranty for the icemaker is printed in
this manual. Keep this manual with your
Refrigerator Owner’s Manual.
Ŷ The icemaker installation inside the freezer is now
complete. Continue to the Water Valve Assembly
section.
9
ATTACH WARRANTY LABEL
Ŷ A labelLVSURYLGHGZLWKWKLVNLWWRUHFRUGWKH
date of installation for warranty purposes. Apply it
to the back of the refrigerator.
7
MOUNT THE ICEMAKER
Ŷ /LIWWKHLFHPDNHUVRWKHILOOtube extension
fits in the fill cup opening&+DQJWKHLFHPDNHU
on the two mounting screws$
Make sure:
Ŷ The power cord is still firmly in the socket.
Ŷ 7KHILOOWXEHH[WHQVLRQLVVWLOOLQWKHILOOFXS
RSHQLQJ&KHFNWKHUHDURIWKHUHIULJHUDWRUWR
make sure the fill tube has not been pushed out of
the back of the refrigerator.)
Ŷ 7KHLFHPDNHUPRXQWLQJVFUHZVDUHORFDWHGLQWKH
uppermost position of the mounting slots.
THEN TIGHTEN THE
ICEMAKER MOUNTING
SCREWS SECURELY.
6
PLUG IN THE ICEMAKER
Ŷ Holding the icemaker in place, insert the power
cord plug into the socket, making sure that the
prongs and holes are matched. Press the plug
firmly into the socket. Lock the plug in place by
clipping the restraints onto each side of the plug.
Make sure the restraints click into place.
13
10
C
A
9
