PATH: SETTINGS  PRODUCT SETUP  COMMUNICATIONS  DNP / IEC104 POINT LISTS  ANALOG INPUT / MME POINTS
Up to 256 analog input points can be configured for the DNP or IEC 60870-5-104 protocols. The analog point list is config-
ured by assigning an appropriate FlexAnalog parameter to each point. Refer to Appendix A: FlexAnalog Parameters for the
full range of assignable parameters.
The DNP / IEC 60870-5-104 point lists always begin with point 0 and end at the first “Off” value. Since DNP / IEC
60870-5-104 point lists must be in one continuous block, any points assigned after the first “Off” point are ignored.
Changes to the DNP / IEC 60870-5-104 point lists will not take effect until the L30 is restarted.
l) IEC 61850 PROTOCOL
PATH: SETTINGS  PRODUCT SETUP  COMMUNICATIONS  IEC 61850 PROTOCOL
The L30 Line Current Differential System is provided with optional IEC 61850 communications capability.
This feature is specified as a software option at the time of ordering. See the Order Codes section in chap-
ter 2 for details.
 ANALOG INPUT / MME
 POINTS
Point: 0
Off
Range: any FlexAnalog parameter
MESSAGE
Point: 1
Off
Range: any FlexAnalog parameter
↓
MESSAGE
Point: 255
Off
Range: any FlexAnalog parameter
 IEC 61850 PROTOCOL

 GSSE / GOOSE
 CONFIGURATION
MESSAGE
 SERVER
 CONFIGURATION
MESSAGE
 IEC 61850 LOGICAL
 NODE NAME PREFIXES
MESSAGE
 MMXU DEADBANDS

MESSAGE
 GGIO1 STATUS
 CONFIGURATION
MESSAGE
 GGIO2 CONTROL
 CONFIGURATION
MESSAGE
 GGIO4 ANALOG
 CONFIGURATION
MESSAGE
 GGIO5 UINTEGER
 CONFIGURATION
MESSAGE
 REPORT CONTROL
 CONFIGURATION
MESSAGE
 XCBR
 CONFIGURATION
MESSAGE
 XSWI
 CONFIGURATION
