GE L30 User Manual

8-22 L30 Line Current Differential System GE Multilin
8.3 FAULT LOCATOR 8 THEORY OF OPERATION
8
Figure 8–10: FAULT LOCATOR SCHEME
SETTINGS
SETTING
FAULT REPORT
SOURCE:
SHOT # FROM
AUTO RECLOSURE
FAULT REPORT
TRIG:
IA
3I_0
I
C
IB
SRC 50DD OPX
VA or VAB
VC or VCA
VB or VBC
827094A5.CDR
Off=0
AND
FAULT
LOCATOR 1
RUN
0
3 SEC
ACTUAL VALUES
DA TE
TIME
FAULT TYPE
FAULT LOCATION
FAULT# RECLOSE SHOT
FAULT REPORT #
Vn or V_0
FAULT REPORT 1 Z1
MAG:
FAULT REPORT 1 Z1
ANGLE:
FAULT REPORT 1 Z0
MAG:
FAULT REPORT 1 Z0
ANGLE:
FAULT REPORT 1
LENGTH UNITS:
FAULT REPORT 1
LENGTH:
FAULT REPORT 1 VT
SUBSTITUTION:
FAULT REP 1
SYSTEM Z0 MAG:
FAULT REP 1
SYSTEM Z0 ANGLE:
