5 SETTINGS 5.2 PRODUCT SETUP
5
The GSSE ID setting represents the IEC 61850 GSSE application ID name string sent as part of each GSSE message. This
string identifies the GSSE message to the receiving device. In L30 releases previous to 5.0x, this name string was repre-
sented by the RELAY NAME setting.
The fixed GOOSE settings are shown below:
PATH: SETTINGS  PRODUCT SETUP  COMMUNICATIONS  IEC 61850 PROTOCOL  GSSE/GOOSE CONFIGURATION
 TRANSMISSION  FIXED GOOSE
These settings are applicable to fixed (DNA/UserSt) GOOSE only.
The GOOSE ID setting represents the IEC 61850 GOOSE application ID (GoID) name string sent as part of each GOOSE
message. This string identifies the GOOSE message to the receiving device. In revisions previous to 5.0x, this name string
was represented by the RELAY NAME setting.
The DESTINATION MAC setting allows the destination Ethernet MAC address to be set. This address must be a multicast
address; the least significant bit of the first byte must be set. In L30 releases previous to 5.0x, the destination Ethernet MAC
address was determined automatically by taking the sending MAC address (that is, the unique, local MAC address of the
L30) and setting the multicast bit.
The
GOOSE VLAN PRIORITY setting indicates the Ethernet priority of GOOSE messages. This allows GOOSE messages to
have higher priority than other Ethernet data. The GOOSE ETYPE APPID setting allows the selection of a specific application
ID for each GOOSE sending device. This value can be left at its default if the feature is not required. Both the GOOSE VLAN
PRIORITY and GOOSE ETYPE APPID settings are required by IEC 61850.
 FIXED GOOSE

GOOSE FUNCTION:
Disabled
Range: Enabled, Disabled
MESSAGE
GOOSE ID:
GOOSEOut
Range: 65-character ASCII string
MESSAGE
DESTINATION MAC:
000000000000
Range: standard MAC address
MESSAGE
GOOSE VLAN PRIORITY:
4
Range: 0 to 7 in steps of 1
MESSAGE
GOOSE VLAN ID:
0
Range: 0 to 4095 in steps of 1
MESSAGE
GOOSE ETYPE APPID:
0
Range: 0 to 16383 in steps of 1
