GE Multilin L30 Line Current Differential System 5-53
5 SETTINGS 5.2 PRODUCT SETUP
5
The report control configuration settings are shown below:
PATH: SETTINGS  PRODUCT SETUP  COMMUNICATIONS  IEC 61850 PROTOCOL  REPORT CONTROL CONFIGURATION
 CONFIGURABLE REPORT 1  REPORT 1 DATASET ITEMS
To create the dataset for logical node LN, program the ITEM 1 to ITEM 64 settings to a value from the list of IEC 61850 data
attributes supported by the L30. Changes to the dataset will only take effect when the L30 is restarted. It is recommended
to use reporting service from logical node LLN0 if a user needs some (but not all) data from already existing GGIO1,
GGIO4, and MMXU4 points and their quantity is not greater than 64 minus the number items in this dataset.
 REPORT 1
 DATASET ITEMS
ITEM 1:
Range: all valid MMS data item references
MESSAGE
ITEM 2:
Range: as shown above
MESSAGE
ITEM 3:
Range: as shown above
↓
MESSAGE
ITEM 64:
Range: as shown above
