GE Multilin L30 Line Current Differential System 5-59
5 SETTINGS 5.2 PRODUCT SETUP
5
The settings for the remaining menus are outlined as follows.
PATH: SETTINGS  PRODUCT SETUP  COMMUNICATIONS  IEC60870-5-103  IEC103 INPUTS BINARY
The binary input points are mapped using elements from a list of possible FlexLogic operands. A maximum of 96 binary
inputs (points) can be mapped this way.
The IEC60870-5-103 point list always starts with point 0 and ends at the first "Off" value. Since the IEC 60870-5-103 point
list must be in a continuous block, any points assigned after the first "Off" point are ignored.
For each defined point, set appropriate values for the Function Type (FUN) and Information Number (INF), which form the
Information Object Identifier field of the ASDU, as defined in IEC60870-5-103.
The binary input points are sent as Class 1 data. They are sent either as a response to a general interrogation received
from the controller or reported spontaneously. Spontaneous transmission occurs as a response to cyclic Class 2 requests.
If the L30 wants to transmit Class 1 data at that time, it demands access for Class 1 data transmission (ACD=1 in the con-
trol field of the response).
For any change to take effect, restart the relay.
 IEC103 INPUTS
 BINARY
 POINT 0

Range: see sub-menu below
MESSAGE
 POINT 1

Range: see sub-menu below
↓
MESSAGE
 POINT 95

Range: see sub-menu below
 POINT 0

POINT 0 FUN
0
Range: 0 to 255 in steps of 1
MESSAGE
POINT 0 INF
0
Range: 0 to 255 in steps of 1
MESSAGE
POINT 0 Input
Off
Range: FlexLogic operand
↓
 POINT 95

POINT 95 FUN
0
Range: 0 to 255 in steps of 1
MESSAGE
POINT 95 INF
0
Range: 0 to 255 in steps of 1
MESSAGE
POINT 95 Input
Off
Range: FlexLogic operand
