GE Multilin L30 Line Current Differential System 5-63
5 SETTINGS 5.2 PRODUCT SETUP
5
Transmitted voltage Vt = (8191/(Vn*2.4)) * V - 4096 =
= (8191/(500000 * 2.4) ) * V - 4096 = 0.0068 * V - 4096
a = 0.0068
Since the step is in increments of 0.001, we round it at:
a = 0.006
b = -4096
Vt = 0.006 * V - 4096
For max voltage 500000V * 2.4 = 1200000V, we transmit
Vt = 0.006 * 1200000 - 4096 = 7200 - 4096 = 3104
PATH: SETTINGS  PRODUCT SETUP  COMMUNICATIONS  IEC60870-5-103  IEC103 COMMANDS
Commands are received as General Command (Type Identification 20). The user can configure which action to perform
when an ASDU command comes.
A list of available mappings is provided on the L30. This includes 64 virtual inputs (see the following table). The ON and
OFF for the same ASDU command can be mapped to different virtual inputs.
Each command is identified by the unique combination made by the function type (FUN), and information number (INF). If
the master sends an ASDU command that does not have the FUN and INF of any configured command, the relay rejects it.
 IEC103 COMMANDS

 COMMAND 0

Range: see sub-menu below
MESSAGE
 COMMAND 1

Range: see sub-menu below
↓
MESSAGE
 COMMAND 31

Range: see sub-menu below
 COMMAND 0

COMMAND 0 FUN:
0
Range: 0 to 255 in steps of 1
MESSAGE
COMMAND 0 INF:
0
Range: 0 to 255 in steps of 1
MESSAGE
COMMAND 0 ON:
Off
Range: Virtual input
MESSAGE
COMMAND 0 OFF:
Off
Range: Virtual input
↓
 COMMAND 31

COMMAND 31 FUN:
0
Range: 0 to 255 in steps of 1
MESSAGE
COMMAND 31 INF:
0
Range: 0 to 255 in steps of 1
MESSAGE
COMMAND 31 ON:
Off
Range: Virtual input
MESSAGE
COMMAND 31 OFF:
Off
Range: Virtual input
