GE L30 User Manual

2-16 L30 Line Current Differential System GE Multilin
2.2 ORDER CODES 2 PRODUCT DESCRIPTION
2
POWER SUPPLY H | | | | | 125 / 250 V AC/DC power supply
L | | | | | 24 to 48 V (DC only) power supply
PROCESS BUS MODULE | 81 | | | Eight-port digital process bus module
DIGITAL INPUTS/OUTPUTS XX XX XX XX No Module
4A | 4 Solid-State (no monitoring) MOSFET outputs
4B | 4 Solid-State (voltage with optional current) MOSFET outputs
4C | 4 Solid-State (current with optional voltage) MOSFET outputs
4D | 16 digital inputs with Auto-Burnishing (maximum of three modules within a case)
4L | 14 Form-A (no monitoring) Latching outputs
67 | 8 Form-A (no monitoring) outputs
6A | 2 Form-A (voltage with optional current) and 2 Form-C outputs, 8 digital inputs
6B | 2 Form-A (voltage with optional current) and 4 Form-C outputs, 4 digital inputs
6C | 8 Form-C outputs
6D | 16 digital inputs
6E | 4 Form-C outputs, 8 digital inputs
6F | 8 Fast Form-C outputs
6G | 4 Form-A (voltage with optional current) outputs, 8 digital inputs
6H | 6 Form-A (voltage with optional current) outputs, 4 digital inputs
6K | 4 Form-C and 4 Fast Form-C outputs
6L | 2 Form-A (current with optional voltage) and 2 Form-C outputs, 8 digital inputs
6M | 2 Form-A (current with optional voltage) and 4 Form-C outputs, 4 digital inputs
6N | 4 Form-A (current with optional voltage) outputs, 8 digital inputs
6P | 6 Form-A (current with optional voltage) outputs, 4 digital inputs
6R | 2 Form-A (no monitoring) and 2 Form-C outputs, 8 digital inputs
6S | 2 Form-A (no monitoring) and 4 Form-C outputs, 4 digital inputs
6T | 4 Form-A (no monitoring) outputs, 8 digital inputs
6U | 6 Form-A (no monitoring) outputs, 4 digital inputs
6V | 2 Form-A outputs, 1 Form-C output, 1 Form-A latching output, 8 digital inputs
INTER-RELAY
COMMUNICATIONS
(select a maximum of 1 per unit)
2A C37.94SM, 1300 nm single-mode, ELED, 1 channel single-mode
2B C37.94SM, 1300 nm single-mode, ELED, 2 channel single-mode
2E Bi-phase, single channel
2F Bi-phase, dual channel
2G IEEE C37.94, 820 nm, 128 kbps, multimode, LED, 1 Channel
2H IEEE C37.94, 820 nm, 128 kbps, multimode, LED, 2 Channels
2I Channel 1 - IEEE C37.94, MM, 64/128 kbps; Channel 2 - 1300 nm, single-mode, Laser
2J Channel 1 - IEEE C37.94, MM, 64/128 kbps; Channel 2 - 1500 nm, single-mode, Laser
72 1550 nm, single-mode, Laser, 1 Channel
73 1550 nm, single-mode, Laser, 2 Channel
74 Channel 1 - RS422; Channel 2 - 1550 nm, single-mode, Laser
75 Channel 1 - G.703; Channel 2 - 1550 nm, single-mode Laser
76 IEEE C37.94, 820 nm, 64 kbps, multimode, LED, 1 Channel
77 IEEE C37.94, 820 nm, 64 kbps, multimode, LED, 2 Channels
7A 820 nm, multimode, LED, 1 Channel
7B 1300 nm, multimode, LED, 1 Channel
7C 1300 nm, single-mode, ELED, 1 Channel
7D 1300 nm, single-mode, Laser, 1 Channel
7E Channel 1 - G.703; Channel 2 - 820 nm, multimode
7F Channel 1 - G.703; Channel 2 - 1300 nm, multimode
7G Channel 1 - G.703; Channel 2 - 1300 nm, single-mode ELED
7H 820 nm, multimode, LED, 2 Channels
7I 1300 nm, multimode, LED, 2 Channels
7J 1300 nm, single-mode, ELED, 2 Channels
7K 1300 nm, single-mode, Laser, 2 Channels
7L Channel 1 - RS422; Channel 2 - 820 nm, multimode, LED
7M Channel 1 - RS422; Channel 2 - 1300 nm, multimode, LED
7N Channel 1 - RS422; Channel 2 - 1300 nm, single-mode, ELED
7P Channel 1 - RS422; Channel 2 - 1300 nm, single-mode, Laser
7Q Channel 1 - G.703; Channel 2 - 1300 nm, single-mode Laser
7R G.703, 1 Channel
7S G.703, 2 Channels
7T RS422, 1 Channel
7V RS422, 2 Channels, 2 Clock Inputs
7W RS422, 2 Channels
Table 2–7: L30 ORDER CODES (REDUCED SIZE VERTICAL UNITS WITH PROCESS BUS)
L30 - * ** - * * * - F ** - H ** - L ** - N ** - R ** Reduced Size Vertical Mount
