B-10 L30 Line Current Differential System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
040F Virtual Input 16 State 0 to 1 --- 1 F108 0 (Off)
0410 Virtual Input 17 State 0 to 1 --- 1 F108 0 (Off)
0411 Virtual Input 18 State 0 to 1 --- 1 F108 0 (Off)
0412 Virtual Input 19 State 0 to 1 --- 1 F108 0 (Off)
0413 Virtual Input 20 State 0 to 1 --- 1 F108 0 (Off)
0414 Virtual Input 21 State 0 to 1 --- 1 F108 0 (Off)
0415 Virtual Input 22 State 0 to 1 --- 1 F108 0 (Off)
0416 Virtual Input 23 State 0 to 1 --- 1 F108 0 (Off)
0417 Virtual Input 24 State 0 to 1 --- 1 F108 0 (Off)
0418 Virtual Input 25 State 0 to 1 --- 1 F108 0 (Off)
0419 Virtual Input 26 State 0 to 1 --- 1 F108 0 (Off)
041A Virtual Input 27 State 0 to 1 --- 1 F108 0 (Off)
041B Virtual Input 28 State 0 to 1 --- 1 F108 0 (Off)
041C Virtual Input 29 State 0 to 1 --- 1 F108 0 (Off)
041D Virtual Input 30 State 0 to 1 --- 1 F108 0 (Off)
041E Virtual Input 31 State 0 to 1 --- 1 F108 0 (Off)
041F Virtual Input 32 State 0 to 1 --- 1 F108 0 (Off)
0420 Virtual Input 33 State 0 to 1 --- 1 F108 0 (Off)
0421 Virtual Input 34 State 0 to 1 --- 1 F108 0 (Off)
0422 Virtual Input 35 State 0 to 1 --- 1 F108 0 (Off)
0423 Virtual Input 36 State 0 to 1 --- 1 F108 0 (Off)
0424 Virtual Input 37 State 0 to 1 --- 1 F108 0 (Off)
0425 Virtual Input 38 State 0 to 1 --- 1 F108 0 (Off)
0426 Virtual Input 39 State 0 to 1 --- 1 F108 0 (Off)
0427 Virtual Input 40 State 0 to 1 --- 1 F108 0 (Off)
0428 Virtual Input 41 State 0 to 1 --- 1 F108 0 (Off)
0429 Virtual Input 42 State 0 to 1 --- 1 F108 0 (Off)
042A Virtual Input 43 State 0 to 1 --- 1 F108 0 (Off)
042B Virtual Input 44 State 0 to 1 --- 1 F108 0 (Off)
042C Virtual Input 45 State 0 to 1 --- 1 F108 0 (Off)
042D Virtual Input 46 State 0 to 1 --- 1 F108 0 (Off)
042E Virtual Input 47 State 0 to 1 --- 1 F108 0 (Off)
042F Virtual Input 48 State 0 to 1 --- 1 F108 0 (Off)
0430 Virtual Input 49 State 0 to 1 --- 1 F108 0 (Off)
0431 Virtual Input 50 State 0 to 1 --- 1 F108 0 (Off)
0432 Virtual Input 51 State 0 to 1 --- 1 F108 0 (Off)
0433 Virtual Input 52 State 0 to 1 --- 1 F108 0 (Off)
0434 Virtual Input 53 State 0 to 1 --- 1 F108 0 (Off)
0435 Virtual Input 54 State 0 to 1 --- 1 F108 0 (Off)
0436 Virtual Input 55 State 0 to 1 --- 1 F108 0 (Off)
0437 Virtual Input 56 State 0 to 1 --- 1 F108 0 (Off)
0438 Virtual Input 57 State 0 to 1 --- 1 F108 0 (Off)
0439 Virtual Input 58 State 0 to 1 --- 1 F108 0 (Off)
043A Virtual Input 59 State 0 to 1 --- 1 F108 0 (Off)
043B Virtual Input 60 State 0 to 1 --- 1 F108 0 (Off)
043C Virtual Input 61 State 0 to 1 --- 1 F108 0 (Off)
043D Virtual Input 62 State 0 to 1 --- 1 F108 0 (Off)
043E Virtual Input 63 State 0 to 1 --- 1 F108 0 (Off)
043F Virtual Input 64 State 0 to 1 --- 1 F108 0 (Off)
IEC103 Protocol Settings (Read/Write Setting)
0582 IEC103 Common ASDU Address 0 to 254 --- 1 F001 0
0583 IEC103 Sync Timeout 1 to 1440 min 1 F001 1
IEC 103 Binary Inputs (Read/Write Setting) (96 modules)
0584 IEC103 Binary Input 1 FUN 0 to 255 --- 1 F001 0
Table B–10: MODBUS MEMORY MAP (Sheet 2 of 63)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
