B-12 L30 Line Current Differential System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
0658 ...Repeated for Binary Input 54
065C ...Repeated for Binary Input 55
0660 ...Repeated for Binary Input 56
0664 ...Repeated for Binary Input 57
0668 ...Repeated for Binary Input 58
066C ...Repeated for Binary Input 59
0670 ...Repeated for Binary Input 60
0674 ...Repeated for Binary Input 61
0678 ...Repeated for Binary Input 62
067C ...Repeated for Binary Input 63
0680 ...Repeated for Binary Input 64
0684 ...Repeated for Binary Input 65
0688 ...Repeated for Binary Input 66
068C ...Repeated for Binary Input 67
0690 ...Repeated for Binary Input 68
0694 ...Repeated for Binary Input 69
0698 ...Repeated for Binary Input 70
069C ...Repeated for Binary Input 71
06A0 ...Repeated for Binary Input 72
06A4 ...Repeated for Binary Input 73
06A8 ...Repeated for Binary Input 74
06AC ...Repeated for Binary Input 75
06B0 ...Repeated for Binary Input 76
06B4 ...Repeated for Binary Input 77
06B8 ...Repeated for Binary Input 78
06BC ...Repeated for Binary Input 79
06C0 ...Repeated for Binary Input 80
06C4 ...Repeated for Binary Input 81
06C8 ...Repeated for Binary Input 82
06CC ...Repeated for Binary Input 83
06D0 ...Repeated for Binary Input 84
06D4 ...Repeated for Binary Input 85
06D8 ...Repeated for Binary Input 86
06DC ...Repeated for Binary Input 87
06E0 ...Repeated for Binary Input 88
06E4 ...Repeated for Binary Input 89
06E8 ...Repeated for Binary Input 90
06EC ...Repeated for Binary Input 91
06F0 ...Repeated for Binary Input 92
06F4 ...Repeated for Binary Input 93
06F8 ...Repeated for Binary Input 94
06FC ...Repeated for Binary Input 95
0700 ...Repeated for Binary Input 96
IEC 103 ASDU Settings (Read/Write Setting) (4 modules)
0704 IEC103 ASDU1 TYP 0 to 1 --- 1 F630 1(9)
0705 IEC103 ASDU 1 FUN 0 to 255 --- 1 F001 0
0706 IEC103 ASDU 1 INF 0 to 255 --- 1 F001 0
0707 IEC103 ASDU 1 Scan Timeout 0 to 1000 --- 1 F001 0
0708 IEC103 ASDU 1 Analog Param 1 0 to 65535 --- 1 F600 0
0709 IEC103 ASDU 1 Analog Factor 1 0 to 65.535 --- 0.001 F001 1000
070A IEC103 ASDU 1 Analog Offset 1 -32768 to 32767 --- 1 F002 0
070B IEC103 ASDU 1 Analog Param 2 0 to 65535 --- 1 F600 0
070C IEC103 ASDU 1 Analog Factor 2 0 to 65.535 --- 0.001 F001 1000
070D IEC103 ASDU 1 Analog Offset 2 -32768 to 32767 --- 1 F002 0
Table B–10: MODBUS MEMORY MAP (Sheet 4 of 63)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
