GE Multilin L30 Line Current Differential System B-21
APPENDIX B B.4 MEMORY MAPPING
B
26F4 IEC 61850 Received uinteger 3 0 to 4294967295 --- 1 F003 0
26F6 IEC 61850 Received uinteger 4 0 to 4294967295 --- 1 F003 0
26F8 IEC 61850 Received uinteger 5 0 to 4294967295 --- 1 F003 0
26FA IEC 61850 Received uinteger 6 0 to 4294967295 --- 1 F003 0
26FC IEC 61850 Received uinteger 7 0 to 4294967295 --- 1 F003 0
26FE IEC 61850 Received uinteger 8 0 to 4294967295 --- 1 F003 0
2700 IEC 61850 Received uinteger 9 0 to 4294967295 --- 1 F003 0
2702 IEC 61850 Received uinteger 10 0 to 4294967295 --- 1 F003 0
2704 IEC 61850 Received uinteger 11 0 to 4294967295 --- 1 F003 0
2706 IEC 61850 Received uinteger 12 0 to 4294967295 --- 1 F003 0
2708 IEC 61850 Received uinteger 13 0 to 4294967295 --- 1 F003 0
270A IEC 61850 Received uinteger 14 0 to 4294967295 --- 1 F003 0
270C IEC 61850 Received uinteger 15 0 to 4294967295 --- 1 F003 0
270E IEC 61850 Received uinteger 16 0 to 4294967295 --- 1 F003 0
Expanded FlexStates (Read Only)
2B00 FlexStates, one per register (256 items) 0 to 1 --- 1 F108 0 (Off)
Expanded Contact Input/Output States (Read Only)
2D00 Contact Input States, one per register (96 items) 0 to 1 --- 1 F108 0 (Off)
2D80 Contact Output States, one per register (64 items) 0 to 1 --- 1 F108 0 (Off)
2E00 Virtual Output States, one per register (96 items) 0 to 1 --- 1 F108 0 (Off)
Expanded Remote Input/Output Status (Read Only)
2F00 Remote Device States, one per register (32 items) 0 to 1 --- 1 F155 0 (Offline)
2F80 Remote Input States, one per register (64 items) 0 to 1 --- 1 F108 0 (Off)
Oscillography Values (Read Only)
3000 Oscillography Number of Triggers 0 to 65535 --- 1 F001 0
3001 Oscillography Available Records 0 to 65535 --- 1 F001 0
3002 Oscillography Last Cleared Date 0 to 400000000 --- 1 F050 0
3004 Oscillography Number Of Cycles Per Record 0 to 65535 --- 1 F001 0
Oscillography Commands (Read/Write Command)
3005 Oscillography Force Trigger 0 to 1 --- 1 F126 0 (No)
3011 Oscillography Clear Data 0 to 1 --- 1 F126 0 (No)
Oscillography Analog Values (Read Only)
3012 Oscillography Number of Triggers 0 to 32767 --- 1 F001 0
Fault Report Indexing (Read Only Non-Volatile)
3020 Number of Fault Reports 0 to 65535 --- 1 F001 0
Fault Report Actual Values (Read Only Non-Volatile) (15 modules)
3030 Fault Report 1 Time 0 to 4294967295 --- 1 F050 0
3032 Fault Report 2 Time 0 to 4294967295 --- 1 F050 0
3034 Fault Report 3 Time 0 to 4294967295 --- 1 F050 0
3036 Fault Report 4 Time 0 to 4294967295 --- 1 F050 0
3038 Fault Report 5 Time 0 to 4294967295 --- 1 F050 0
303A Fault Report 6 Time 0 to 4294967295 --- 1 F050 0
303C Fault Report 7 Time 0 to 4294967295 --- 1 F050 0
303E Fault Report 8 Time 0 to 4294967295 --- 1 F050 0
3040 Fault Report 9 Time 0 to 4294967295 --- 1 F050 0
3042 Fault Report 10 Time 0 to 4294967295 --- 1 F050 0
3044 Fault Report 11 Time 0 to 4294967295 --- 1 F050 0
3046 Fault Report 12 Time 0 to 4294967295 --- 1 F050 0
3048 Fault Report 13 Time 0 to 4294967295 --- 1 F050 0
304A Fault Report 14 Time 0 to 4294967295 --- 1 F050 0
304C Fault Report 15 Time 0 to 4294967295 --- 1 F050 0
Modbus File Transfer (Read/Write)
3100 Name of file to read --- --- --- F204 (none)
Table B–10: MODBUS MEMORY MAP (Sheet 13 of 63)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
