GE Multilin L30 Line Current Differential System B-37
APPENDIX B B.4 MEMORY MAPPING
B
5518 ...Repeated for RTD Input 15
552C ...Repeated for RTD Input 16
5540 ...Repeated for RTD Input 17
5554 ...Repeated for RTD Input 18
5568 ...Repeated for RTD Input 19
557C ...Repeated for RTD Input 20
5590 ...Repeated for RTD Input 21
55A4 ...Repeated for RTD Input 22
55B8 ...Repeated for RTD Input 23
55CC ...Repeated for RTD Input 24
55E0 ...Repeated for RTD Input 25
55F4 ...Repeated for RTD Input 26
5608 ...Repeated for RTD Input 27
561C ...Repeated for RTD Input 28
5630 ...Repeated for RTD Input 29
5644 ...Repeated for RTD Input 30
5658 ...Repeated for RTD Input 31
566C ...Repeated for RTD Input 32
5680 ...Repeated for RTD Input 33
5694 ...Repeated for RTD Input 34
56A8 ...Repeated for RTD Input 35
56BC ...Repeated for RTD Input 36
56D0 ...Repeated for RTD Input 37
56E4 ...Repeated for RTD Input 38
56F8 ...Repeated for RTD Input 39
570C ...Repeated for RTD Input 40
5720 ...Repeated for RTD Input 41
5734 ...Repeated for RTD Input 42
5748 ...Repeated for RTD Input 43
575C ...Repeated for RTD Input 44
5770 ...Repeated for RTD Input 45
5784 ...Repeated for RTD Input 46
5798 ...Repeated for RTD Input 47
57AC ...Repeated for RTD Input 48
FlexLogic Timers (Read/Write Setting) (32 modules)
5800 FlexLogic Timer 1 Type 0 to 2 --- 1 F129 0 (millisecond)
5801 FlexLogic Timer 1 Pickup Delay 0 to 60000 --- 1 F001 0
5802 FlexLogic Timer 1 Dropout Delay 0 to 60000 --- 1 F001 0
5803 Reserved (5 items) 0 to 65535 --- 1 F001 0
5808 ...Repeated for FlexLogic Timer 2
5810 ...Repeated for FlexLogic Timer 3
5818 ...Repeated for FlexLogic Timer 4
5820 ...Repeated for FlexLogic Timer 5
5828 ...Repeated for FlexLogic Timer 6
5830 ...Repeated for FlexLogic Timer 7
5838 ...Repeated for FlexLogic Timer 8
5840 ...Repeated for FlexLogic Timer 9
5848 ...Repeated for FlexLogic Timer 10
5850 ...Repeated for FlexLogic Timer 11
5858 ...Repeated for FlexLogic Timer 12
5860 ...Repeated for FlexLogic Timer 13
5868 ...Repeated for FlexLogic Timer 14
5870 ...Repeated for FlexLogic Timer 15
5878 ...Repeated for FlexLogic Timer 16
Table B–10: MODBUS MEMORY MAP (Sheet 29 of 63)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
