GE Multilin L30 Line Current Differential System B-47
APPENDIX B B.4 MEMORY MAPPING
B
8627 Breaker Failure 1 Breaker Status 1 Phase C 0 to 4294967295 --- 1 F300 0
8629 Breaker Failure 1 Breaker Status 2 Phase B 0 to 4294967295 --- 1 F300 0
862B Breaker Failure 1 Breaker Status 2 Phase C 0 to 4294967295 --- 1 F300 0
862D ...Repeated for Breaker Failure 2
FlexState Settings (Read/Write Setting)
8800 FlexState Parameters (256 items) 0 to 4294967295 --- 1 F300 0
Digital Elements (Read/Write Setting) (48 modules)
8A00 Digital Element 1 Function 0 to 1 --- 1 F102 0 (Disabled)
8A01 Digital Element 1 Name --- --- --- F203 “Dig Element 1“
8A09 Digital Element 1 Input 0 to 4294967295 --- 1 F300 0
8A0B Digital Element 1 Pickup Delay 0 to 999999.999 s 0.001 F003 0
8A0D Digital Element 1 Reset Delay 0 to 999999.999 s 0.001 F003 0
8A0F Digital Element 1 Block 0 to 4294967295 --- 1 F300 0
8A11 Digital Element 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
8A12 Digital Element 1 Events 0 to 1 --- 1 F102 0 (Disabled)
8A13 Digital Element 1 Pickup LED 0 to 1 --- 1 F102 1 (Enabled)
8A14 Reserved (2 items) --- --- --- F001 0
8A16 ...Repeated for Digital Element 2
8A2C ...Repeated for Digital Element 3
8A42 ...Repeated for Digital Element 4
8A58 ...Repeated for Digital Element 5
8A6E ...Repeated for Digital Element 6
8A84 ...Repeated for Digital Element 7
8A9A ...Repeated for Digital Element 8
8AB0 ...Repeated for Digital Element 9
8AC6 ...Repeated for Digital Element 10
8ADC ...Repeated for Digital Element 11
8AF2 ...Repeated for Digital Element 12
8B08 ...Repeated for Digital Element 13
8B1E ...Repeated for Digital Element 14
8B34 ...Repeated for Digital Element 15
8B4A ...Repeated for Digital Element 16
8B60 ...Repeated for Digital Element 17
8B76 ...Repeated for Digital Element 18
8B8C ...Repeated for Digital Element 19
8BA2 ...Repeated for Digital Element 20
8BB8 ...Repeated for Digital Element 21
8BCE ...Repeated for Digital Element 22
8BE4 ...Repeated for Digital Element 23
8BFA ...Repeated for Digital Element 24
8C10 ...Repeated for Digital Element 25
8C26 ...Repeated for Digital Element 26
8C3C ...Repeated for Digital Element 27
8C52 ...Repeated for Digital Element 28
8C68 ...Repeated for Digital Element 29
8C7E ...Repeated for Digital Element 30
8C94 ...Repeated for Digital Element 31
8CAA ...Repeated for Digital Element 32
8CC0 ...Repeated for Digital Element 33
8CD6 ...Repeated for Digital Element 34
8CEC ...Repeated for Digital Element 35
8D02 ...Repeated for Digital Element 36
8D18 ...Repeated for Digital Element 37
8D2E ...Repeated for Digital Element 38
Table B–10: MODBUS MEMORY MAP (Sheet 39 of 63)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
