GE Multilin L30 Line Current Differential System B-53
APPENDIX B B.4 MEMORY MAPPING
B
IEC 61850 GGIO4 General Analog Configuration Settings (Read/Write)
AF00 Number of Analog Input Points in GGIO4 4 to 32 --- 4 F001 4
IEC 61850 GGIO4 Analog Input Points Configuration Settings (Read/Write Setting) (32 modules)
AF10 IEC 61850 GGIO4 Analog Input 1 Value --- --- --- F600 0
AF11 IEC 61850 GGIO4 Analog Input 1 Deadband 0.001 to 100 % 0.001 F003 100000
AF13 IEC 61850 GGIO4 Analog Input 1 Minimum –1000000000000 to
1000000000000
--- 0.001 F060 0
AF15 IEC 61850 GGIO4 Analog Input 1 Maximum –1000000000000 to
1000000000000
--- 0.001 F060 1000000
AF17 ...Repeated for IEC 61850 GGIO4 Analog Input 2
AF1E ...Repeated for IEC 61850 GGIO4 Analog Input 3
AF25 ...Repeated for IEC 61850 GGIO4 Analog Input 4
AF2C ...Repeated for IEC 61850 GGIO4 Analog Input 5
AF33 ...Repeated for IEC 61850 GGIO4 Analog Input 6
AF3A ...Repeated for IEC 61850 GGIO4 Analog Input 7
AF41 ...Repeated for IEC 61850 GGIO4 Analog Input 8
AF48 ...Repeated for IEC 61850 GGIO4 Analog Input 9
AF4F ...Repeated for IEC 61850 GGIO4 Analog Input 10
AF56 ...Repeated for IEC 61850 GGIO4 Analog Input 11
AF5D ...Repeated for IEC 61850 GGIO4 Analog Input 12
AF64 ...Repeated for IEC 61850 GGIO4 Analog Input 13
AF6B ...Repeated for IEC 61850 GGIO4 Analog Input 14
AF72 ...Repeated for IEC 61850 GGIO4 Analog Input 15
AF79 ...Repeated for IEC 61850 GGIO4 Analog Input 16
AF80 ...Repeated for IEC 61850 GGIO4 Analog Input 17
AF87 ...Repeated for IEC 61850 GGIO4 Analog Input 18
AF8E ...Repeated for IEC 61850 GGIO4 Analog Input 19
AF95 ...Repeated for IEC 61850 GGIO4 Analog Input 20
AF9C ...Repeated for IEC 61850 GGIO4 Analog Input 21
AFA3 ...Repeated for IEC 61850 GGIO4 Analog Input 22
AFAA ...Repeated for IEC 61850 GGIO4 Analog Input 23
AFB1 ...Repeated for IEC 61850 GGIO4 Analog Input 24
AFB8 ...Repeated for IEC 61850 GGIO4 Analog Input 25
AFBF ...Repeated for IEC 61850 GGIO4 Analog Input 26
AFC6 ...Repeated for IEC 61850 GGIO4 Analog Input 27
AFCD ...Repeated for IEC 61850 GGIO4 Analog Input 28
AFD4 ...Repeated for IEC 61850 GGIO4 Analog Input 29
AFDB ...Repeated for IEC 61850 GGIO4 Analog Input 30
AFE2 ...Repeated for IEC 61850 GGIO4 Analog Input 31
AFE9 ...Repeated for IEC 61850 GGIO4 Analog Input 32
IEC 61850 GOOSE/GSSE Configuration (Read/Write Setting)
B01C Default GOOSE/GSSE Update Time 1 to 60 s 1 F001 60
B01D IEC 61850 GSSE Function (GsEna) 0 to 1 --- 1 F102 1 (Enabled)
B01E IEC 61850 GSSE ID --- --- --- F209 “GSSEOut”
B03F IEC 61850 GOOSE Function (GoEna) 0 to 1 --- 1 F102 0 (Disabled)
B040 IEC 61850 GSSE Destination MAC Address --- --- --- F072 0
B043 IEC 61850 Standard GOOSE ID --- --- --- F209 “GOOSEOut”
B064 IEC 61850 Standard GOOSE Destination MAC Address --- --- --- F072 0
B067 IEC 61850 GOOSE VLAN Transmit Priority 0 to 7 --- 1 F001 4
B068 IEC 61850 GOOSE VLAN ID 0 to 4095 --- 1 F001 0
B069 IEC 61850 GOOSE ETYPE APPID 0 to 16383 --- 1 F001 0
B06A Reserved (2 items) 0 to 1 --- 1 F001 0
IEC 61850 Server Configuration (Read/Write Settings/Commands)
B06C TCP Port Number for the IEC 61850 / MMS Protocol 0 to 65535 --- 1 F001 102
B06D IEC 61850 Logical Device Name --- --- --- F213 “IEDName”
Table B–10: MODBUS MEMORY MAP (Sheet 45 of 63)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
