GE Multilin L30 Line Current Differential System B-69
APPENDIX B B.4 MEMORY MAPPING
B
DD62 PMU 1 A-CH-x (16 items) 0 to 65535 --- 1 F600 0
DD72 PMU 1 A-CH-x (16 items) --- --- --- F203 "AnalogChannel 1
"
DDF2 PMU 1 D-CH-x (16 items) 0 to 4294967295 --- 1 F300 0
DE12 PMU 1 D-CH-x Name (16 items) --- --- --- F203 "Dig Channel 1 "
DE92 PMU 1 D-CH-x Normal State (16 items) 0 to 1 --- 1 F108 0 (Off)
DEA2 PMU 1 Reserved (16 items) 0 to 1 --- 1 F001 0
Phasor Measurement Unit Aggregator (Read/Write Setting)
E8A8 PMU Aggregator 1 Name --- --- 1 F209 "MSVID 1 "
E8C9 Aggregator 1 IDcode 1 to 65534 --- 1 F001 1
E8CA Aggregator 1 Protocol 0 to 2 --- 1 F548 0 (NONE)
E8CB Aggregator 1 TCP Port 0 to 65534 --- 1 F001 4712
E8CC Aggregator 1 UDP Port 0 to 65534 --- 1 F001 4713
E8CD PMU Aggregator 1 90-5 UDP Port 0 to 65534 --- 1 F001 102
E8CE PMU Aggregator 1 PDC Network Control 0 to 1 --- 1 F102 0 (Disabled)
E8CF Aggregator 1 Include PMU1 0 to 1 --- 1 F126 0 (No)
E8D0 Aggregator 1 Include PMU2 0 to 1 --- 1 F126 0 (No)
E8D1 Aggregator 1 Include PMU3 0 to 1 --- 1 F126 0 (No)
E8D2 Aggregator 1 Include PMU4 0 to 1 --- 1 F126 0 (No)
E8D3 Aggregator 1 Include PMU5 0 to 1 --- 1 F126 0 (No)
E8D4 Aggregator 1 Include PMU6 0 to 1 --- 1 F126 0 (No)
E8D5 PMU Aggregator 1 ASDUS 1 to 4 --- 1 F001 1
E8D6 PMU Aggregator 1 Port 1 to 3 --- 1 F001 1
E8D7 PMU Aggregator 1 Reserved (3 items) 0 to 1 --- 1 F001 0
Phasor Measurement Unit Aggregator Control Block (Read/Write Setting)
E9C8 PMU Aggregator 1 Control Block SvEna 0 to 4294967295 --- 1 F300 0
E9CA PMU Aggregator 1 Control Block Client Control 0 to 4294967295 --- 1 F300 0
E9CC PMU Aggregator 1 CB SvEna Default 0 to 4294967295 --- 1 F300 0
E9CE PMU Aggregator 1 Control Block ConfRev 1 to 4294967295 --- 1 F003 1
E9D0 PMU Aggregator 1 Control Block Priority 0 to 7 --- 1 F001 4
E9D1 PMU Aggregator 1 Control Block IPClass 0 to 1 --- 1 F563 1 (Expedited
Forwarding)
E9D2 PMU Aggregator 1 Control Block VID 0 to 4095 --- 1 F001 0
E9D3 PMU Aggregator 1 Control Block APPID 0 to 16383 --- 1 F001 0
E9D4 PMU Aggregator 1 Control Block IP Address 0 to 4294967295 --- 1 F003 0
E9D6 PMU Aggregator 1 Control Block Security 0 to 2 --- 1 F001 0
Phasor Measurement Unit Recording Command (Read/Write Command)
EA22 PMU 1 Recording Clear Command 0 to 1 --- 1 F126 0 (No)
EA23 PMU 1 Recording Force Trigger 0 to 1 --- 1 F126 0 (No)
Phasor Measurement Unit Recording (Read/Write Setting)
EA2E PMU 1 Record Function 0 to 1 --- 1 F102 0 (Disabled)
EA2F PMU 1 No of Timed Records 2 to 128 --- 1 F001 10
EA30 PMU 1 Trigger Mode 0 to 1 --- 1 F542 0 (Auto
Overwrite)
EA31 .PMU 1 Timed Trigger Position 1 to 50 % 1 F001 10
Phasor Measurement Unit Recording Ex (Read/Write Setting)
Phasor Measurement Unit Triggering (Read/Write Setting)
EA4A PMU 1 User Trigger 0 to 4294967295 --- 1 F300 0
Phasor Measurement Unit Voltage Trigger (Read/Write Setting)
EA56 PMU 1 Volt Trigger Function 0 to 1 --- 1 F102 0 (Disabled)
EA57 PMU 1 Voltage Trigger Low Volt 0.25 to 1.25 pu 0.001 F001 800
EA58 PMU 1 Voltage Trigger High Volt 0.75 to 1.75 pu 0.001 F001 1200
EA59 PMU 1 Voltage Trigger Pkp Time 0 to 600 s 0.01 F001 10
EA5A PMU 1 Voltage Trigger Dpo Time 0 to 600 s 0.01 F001 100
EA5B PMU 1 Voltage Trigger Block (3 items) 0 to 4294967295 --- 1 F300 0
Table B–10: MODBUS MEMORY MAP (Sheet 61 of 63)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
