GE Multilin L30 Line Current Differential System B-73
APPENDIX B B.4 MEMORY MAPPING
B
F103
ENUMERATION: CURVE SHAPES
F104
ENUMERATION: RESET TYPE
0 = Instantaneous, 1 = Timed
F106
ENUMERATION: PHASE ROTATION
0 = ABC, 1 = ACB
F108
ENUMERATION: OFF/ON
0 = Off, 1 = On
F109
ENUMERATION: CONTACT OUTPUT OPERATION
0 = Self-reset, 1 = Latched, 2 = Disabled
F111
ENUMERATION: UNDERVOLTAGE CURVE SHAPES
0 = Definite Time, 1 = Inverse Time
F112
ENUMERATION: RS485 BAUD RATES
F113
ENUMERATION: PARITY
0 = None, 1 = Odd, 2 = Even
F114
ENUMERATION: IRIG-B SIGNAL TYPE
0 = None, 1 = DC Shift, 2 = Amplitude Modulated
F118
ENUMERATION: OSCILLOGRAPHY MODE
0 = Automatic Overwrite, 1 = Protected
F122
ENUMERATION: ELEMENT INPUT SIGNAL TYPE
0 = Phasor, 1 = RMS
F123
ENUMERATION: CT SECONDARY
0 = 1 A, 1 = 5 A
F124
ENUMERATION: LIST OF ELEMENTS
Bitmask Curve shape Bitmask Curve shape
0 IEEE Mod Inv 9 IAC Inverse
1 IEEE Very Inv 10 IAC Short Inv
2 IEEE Ext Inv 11 I2t
3 IEC Curve A 12 Definite Time
4 IEC Curve B 13 FlexCurve A
5 IEC Curve C 14 FlexCurve B
6 IEC Short Inv 15 FlexCurve C
7 IAC Ext Inv 16 FlexCurve D
8 IAC Very Inv
Bitmask Value Bitmask Value Bitmask Value
0 300 4 9600 8 115200
1 1200 5 19200 9 14400
2 2400 6 38400 10 28800
3 4800 7 57600 11 33600
Bitmask Element
0 Phase Instantaneous Overcurrent 1
1 Phase Instantaneous Overcurrent 2
2 Phase Instantaneous Overcurrent 3
3 Phase Instantaneous Overcurrent 4
16 Phase Time Overcurrent 1
17 Phase Time Overcurrent 2
24 Phase Directional Overcurrent 1
25 Phase Directional Overcurrent 2
32 Neutral Instantaneous Overcurrent 1
33 Neutral Instantaneous Overcurrent 2
34 Neutral Instantaneous Overcurrent 3
35 Neutral Instantaneous Overcurrent 4
48 Neutral Time Overcurrent 1
49 Neutral Time Overcurrent 2
56 Neutral Directional Overcurrent 1
57 Neutral Directional Overcurrent 2
64 Ground Instantaneous Overcurrent 1
65 Ground Instantaneous Overcurrent 2
66 Ground Instantaneous Overcurrent 3
67 Ground Instantaneous Overcurrent 4
68 Ground Instantaneous Overcurrent 5
69 Ground Instantaneous Overcurrent 6
70 Ground Instantaneous Overcurrent 7
71 Ground Instantaneous Overcurrent 8
80 Ground Time Overcurrent 1
81 Ground Time Overcurrent 2
82 Ground Time Overcurrent 3
83 Ground Time Overcurrent 4
96 Negative Sequence Instantaneous Overcurrent 1
97 Negative Sequence Instantaneous Overcurrent 2
112 Negative Sequence Time Overcurrent 1
