B-78 L30 Line Current Differential System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
F156
ENUMERATION: REMOTE INPUT BIT PAIRS
F157
ENUMERATION: BREAKER MODE
0 = 3-Pole, 1 = 1-Pole
F166
ENUMERATION: AUXILIARY VT CONNECTION TYPE
0 = Vn, 1 = Vag, 2 = Vbg, 3 = Vcg, 4 = Vab, 5 = Vbc, 6 = Vca
F167
ENUMERATION: SIGNAL SOURCE
0 = SRC 1, 1 = SRC 2, 2 = SRC 3, 3 = SRC 4,
4 = SRC 5, 5 = SRC 6
F172
ENUMERATION: SLOT LETTERS
F173
ENUMERATION: DCmA INPUT/OUTPUT RANGE
F174
ENUMERATION: TRANSDUCER RTD INPUT TYPE
0 = 100 Ohm Platinum, 1 = 120 Ohm Nickel,
2 = 100 Ohm Nickel, 3 = 10 Ohm Copper
F176
ENUMERATION: SYNCHROCHECK DEAD SOURCE SELECT
F177
ENUMERATION: COMMUNICATION PORT
0 = None, 1 = COM1-RS485 (not applicable to UR firmware 7.00),
2 = COM2-RS485, 3 = Front Panel-RS232, 4 = Network - TCP,
5 = Network - UDP
Bitmask Value Bitmask Value
0 None 35 UserSt-3
1 DNA-1 36 UserSt-4
2 DNA-2 37 UserSt-5
3 DNA-3 38 UserSt-6
4 DNA-4 39 UserSt-7
5 DNA-5 40 UserSt-8
6 DNA-6 41 UserSt-9
7 DNA-7 42 UserSt-10
8 DNA-8 43 UserSt-11
9 DNA-9 44 UserSt-12
10 DNA-10 45 UserSt-13
11 DNA-11 46 UserSt-14
12 DNA-12 47 UserSt-15
13 DNA-13 48 UserSt-16
14 DNA-14 49 UserSt-17
15 DNA-15 50 UserSt-18
16 DNA-16 51 UserSt-19
17 DNA-17 52 UserSt-20
18 DNA-18 53 UserSt-21
19 DNA-19 54 UserSt-22
20 DNA-20 55 UserSt-23
21 DNA-21 56 UserSt-24
22 DNA-22 57 UserSt-25
23 DNA-23 58 UserSt-26
24 DNA-24 59 UserSt-27
25 DNA-25 60 UserSt-28
26 DNA-26 61 UserSt-29
27 DNA-27 62 UserSt-30
28 DNA-28 63 UserSt-31
29 DNA-29 64 UserSt-32
30 DNA-30 65 Dataset Item 1
31 DNA-31 66 Dataset Item 2
32 DNA-32 67 Dataset Item 3
33 UserSt-1 ↓↓
34 UserSt-2 96 Dataset Item 32
Bitmas
k
Slot Bitmas
k
Slot Bitmas
k
Slot Bitmas
k
Slot
0F 4K 8P 12U
1G 5L 9R 13V
2H 6M 10S 14W
3J 7N 11T 15X
Bitmask DCmA input/output range
0 0 to –1 mA
1 0 to 1 mA
2 –1 to 1 mA
3 0 to 5 mA
4 0 to 10 mA
5 0 to 20 mA
6 4 to 20 mA
Bitmask Synchrocheck dead source
0None
1 LV1 and DV2
2 DV1 and LV2
3DV1 or DV2
4 DV1 Xor DV2
5 DV1 and DV2
