B-80 L30 Line Current Differential System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
F203
TEXT16: 16-CHARACTER ASCII TEXT
F204
TEXT80: 80-CHARACTER ASCII TEXT
F205
TEXT12: 12-CHARACTER ASCII TEXT
F206
TEXT6: 6-CHARACTER ASCII TEXT
F207
TEXT4: 4-CHARACTER ASCII TEXT
F209
TEXT65: 65-CHARACTER ASCII TEXT
F213
TEXT32: 32-CHARACTER ASCII TEXT
F214
TEXT64: 64-CHARACTER ASCII TEXTF220
ENUMERATION: PUSHBUTTON MESSAGE PRIORITY
F223
ENUMERATION: DIAGNOSTIC TEST
0 = No Test, 1 = Run Test, 2 = End Test
F230
ENUMERATION: DIRECTIONAL POLARIZING
0 = Voltage, 1 = Current, 2 = Dual, 3 = Dual-V, 4 = Dual-I
F231
ENUMERATION: POLARIZING VOLTAGE
0 = Calculated V0, 1 = Measured VXF232
ENUMERATION: CONFIGURABLE GOOSE Tx
DATASET ITEMS
Value Priority
0Disabled
1 Normal
2 High Priority
Value IEC 61850 Tx dataset item
0None
1 GGIO1.ST.Ind1.q
2 GGIO1.ST.Ind1.stVal
3 GGIO1.ST.Ind2.q
4 GGIO1.ST.Ind2.stVal
↓↓
255 GGIO1.ST.Ind128.q
256 GGIO1.ST.Ind128.stVal
257 MMXU1.MX.TotW.mag.f
258 MMXU1.MX.TotVAr.mag.f
259 MMXU1.MX.TotVA.mag.f
260 MMXU1.MX.TotPF.mag.f
261 MMXU1.MX.Hz.mag.f
262 MMXU1.MX.PPV.phsAB.cVal.mag.f
263 MMXU1.MX.PPV.phsAB.cVal.ang.f
264 MMXU1.MX.PPV.phsBC.cVal.mag.f
265 MMXU1.MX.PPV.phsBC.cVal.ang.f
266 MMXU1.MX.PPV.phsCA.cVal.mag.f
267 MMXU1.MX.PPV.phsCA.cVal.ang.f
268 MMXU1.MX.PhV.phsA.cVal.mag.f
269 MMXU1.MX.PhV.phsA.cVal.ang.f
270 MMXU1.MX.PhV.phsB.cVal.mag.f
271 MMXU1.MX.PhV.phsB.cVal.ang.f
272 MMXU1.MX.PhV.phsC.cVal.mag.f
273 MMXU1.MX.PhV.phsC.cVal.ang.f
274 MMXU1.MX.A.phsA.cVal.mag.f
275 MMXU1.MX.A.phsA.cVal.ang.f
276 MMXU1.MX.A.phsB.cVal.mag.f
277 MMXU1.MX.A.phsB.cVal.ang.f
278 MMXU1.MX.A.phsC.cVal.mag.f
279 MMXU1.MX.A.phsC.cVal.ang.f
280 MMXU1.MX.A.neut.cVal.mag.f
281 MMXU1.MX.A.neut.cVal.ang.f
282 MMXU1.MX.W.phsA.cVal.mag.f
283 MMXU1.MX.W.phsB.cVal.mag.f
284 MMXU1.MX.W.phsC.cVal.mag.f
285 MMXU1.MX.VAr.phsA.cVal.mag.f
286 MMXU1.MX.VAr.phsB.cVal.mag.f
287 MMXU1.MX.VAr.phsC.cVal.mag.f
288 MMXU1.MX.VA.phsA.cVal.mag.f
289 MMXU1.MX.VA.phsB.cVal.mag.f
290 MMXU1.MX.VA.phsC.cVal.mag.f
291 MMXU1.MX.PF.phsA.cVal.mag.f
292 MMXU1.MX.PF.phsB.cVal.mag.f
293 MMXU1.MX.PF.phsC.cVal.mag.f
294 MMXU2.MX.TotW.mag.f
295 MMXU2.MX.TotVAr.mag.f
296 MMXU2.MX.TotVA.mag.f
297 MMXU2.MX.TotPF.mag.f
298 MMXU2.MX.Hz.mag.f
299 MMXU2.MX.PPV.phsAB.cVal.mag.f
300 MMXU2.MX.PPV.phsAB.cVal.ang.f
301 MMXU2.MX.PPV.phsBC.cVal.mag.f
302 MMXU2.MX.PPV.phsBC.cVal.ang.f
303 MMXU2.MX.PPV.phsCA.cVal.mag.f
304 MMXU2.MX.PPV.phsCA.cVal.ang.f
305 MMXU2.MX.PhV.phsA.cVal.mag.f
Value IEC 61850 Tx dataset item
