GE L30

B-84 L30 Line Current Differential System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
F237
ENUMERATION: REAL TIME CLOCK MONTH (FOR EXAMPLE,
DAYLIGHT SAVINGS TIME)
F238
ENUMERATION: REAL TIME CLOCK DAY (FOR EXAMPLE,
DAYLIGHT SAVINGS TIME)
F239
ENUMERATION: REAL TIME CLOCK DAYLIGHT SAVINGS
TIME START DAY INSTANCE
F243
ENUMERATION: FIELD UNIT TYPE
0 = CC-05, 1 = CV-05, 2 = CC-01, 3 = CV-01
F244
ENUMERATION: FIELD UNIT PROCESS CARD PORT
0 = H4a, 1 = H4b, 2 = H3a, 3 = H3b, 4 = H2a, 5 = H2b, 6 = H1a,
7 = H1b
F245
ENUMERATION: TEST MODE FUNCTION
F246
ENUMERATION: BRICK TRANSDUCER RANGE
F247
ENUMERATION: BRICK AC BANK ORIGIN
194 GGIO3.ST.UIntIn15.q
195 GGIO3.ST.UIntIn15.stVal
196 GGIO3.ST.UIntIn16.q
197 GGIO3.ST.UIntIn16.stVal
Value Month
0 January
1 February
2March
3April
4May
5June
6July
7 August
8 September
9 October
10 November
11 December
Value Day
0 Sunday
1 Monday
2 Tuesday
3 Wednesday
4 Thursday
5 Friday
6 Saturday
Value Instance
0First
1 Second
2Third
3Fourth
4 Last
Value IEC 61850 GOOSE Rx dataset
item
Value Instance
0 Disabled
1 Isolated
2 Forcible
Value Description
0 -5...5V
1 -1...1mA
2 0...1mA
3 0...-1mA
4 0...5mA
5 0...10mA
6 0...20mA
7 4...20mA
8 potentiometer
9 tap position
Value Description
0None
1U1/AC1..3
2U1/AC5..7
3U2/AC1..3
4U2/AC5..7
5U3/AC1..3
6U3/AC5..7
7U4/AC1..3
8U4/AC5..7
9U5/AC1..3
10 U5/AC5..7
11 U6/AC1..3
12 U6/AC5..7
13 U7/AC1..3
14 U7/AC5..7
15 U8/AC1..3
16 U8/AC5..7
