B-88 L30 Line Current Differential System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
F561
ENUMERATION: 87L INRUSH INHIBIT MODE
F562
ENUMERATION: 87L IN-ZONE TRANSFORMER LOCATION
F563
ENUMERATION: DSCP TYPE
F600
UR_UINT16: FLEXANALOG PARAMETER
Corresponds to the Modbus address of the value used when this
parameter is selected. Only certain values can be used as FlexAn-
alogs (basically all metering quantities used in protection).
F601
ENUMERATION: COM2 PORT USAGE
F605
ENUMERATION: REMOTE DOUBLE-POINT STATUS INPUT
STATUS
F606
ENUMERATION: REMOTE DOUBLE-POINT STATUS INPUT
F611
ENUMERATION: GOOSE RETRANSMISSION CURVE
F612
UR_UINT16: FLEXINTEGER PARAMETER
This 16-bit value corresponds to the Modbus address of the
selected FlexInteger parameter. Only certain values can be used
as FlexIntegers. There is no operation executed even though they
are called FlexIntegers.
F615
ENUMERATION: IEC 61850 REPORT DATASET ITEMS
Enumeration Inrush inhibit mode
0Disabled
1 Per phase
2 Two out of three
3Average
Enumeration In-zone transformer location
0 Local-tap
1 Remote 1-tap
2 Remote 2-tap
Enumeration DSCP type
0None
1 Expedited Forwarding
Enumeration COM2 port usage
0 RS485
1RRTD
2 GPM-F
3 RRTD and GPM-F
Enumeration Remote DPS input status
0 Intermediate
1Off
2On
3Bad
Enumeration Remote double-point status input
0None
1 Remote input 1
2 Remote input 2
3 Remote input 3
↓↓
64 Remote input 64
Enumeration Configurable GOOSE retransmission scheme
0 Heartbeat
1 Aggressive
2Medium
3 Relaxed
Enumeration IEC 61850 report dataset items
0None
1 PDIF1.ST.Str.general
2 PDIF1.ST.Op.general
3 PDIF2.ST.Str.general
4 PDIF2.ST.Op.general
5 PDIF3.ST.Str.general
6 PDIF3.ST.Op.general
7 PDIF4.ST.Str.general
8 PDIF4.ST.Op.general
9 PDIS1.ST.Str.general
10 PDIS1.ST.Op.general
11 PDIS2.ST.Str.general
12 PDIS2.ST.Op.general
13 PDIS3.ST.Str.general
14 PDIS3.ST.Op.general
15 PDIS4.ST.Str.general
16 PDIS4.ST.Op.general
17 PDIS5.ST.Str.general
18 PDIS5.ST.Op.general
19 PDIS6.ST.Str.general
20 PDIS6.ST.Op.general
21 PDIS7.ST.Str.general
22 PDIS7.ST.Op.general
