B-106 L30 Line Current Differential System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
F617
ENUMERATION: LOGIN ROLES
F618
BITFIED: SECURITY STATUS INDICATOR
Has been activated, whether the password has been set.
1 = Bit#0, Administrator password was set. The list is continued for
all other roles (Engineer = bit#2, Operator = bit#3, Observer =
bit#3).
F619
ENUMERATION: RADIUS AUTHENTICATION METHOD
0 = EAP-TTLS
F621
ENUMERATION: MODBUS LOGIN ROLES
x
F623
ENUMERATION: REAL-TIME CLOCK SYNCHRONIZING
SOURCE CONFIGURATION
F624
ENUMERATION: REAL-TIME CLOCK SYNCHRONZING
SOURCE ACTUALS
F625
ENUMERATION: PTP STATE
971 XSWI12.ST.Loc.stVal
972 XSWI12.ST.Pos.stVal
973 XSWI13.ST.Loc.stVal
974 XSWI13.ST.Pos.stVal
975 XSWI14.ST.Loc.stVal
976 XSWI14.ST.Pos.stVal
977 XSWI15.ST.Loc.stVal
978 XSWI15.ST.Pos.stVal
979 XSWI16.ST.Loc.stVal
980 XSWI16.ST.Pos.stVal
981 XSWI17.ST.Loc.stVal
982 XSWI17.ST.Pos.stVal
983 XSWI18.ST.Loc.stVal
984 XSWI18.ST.Pos.stVal
985 XSWI19.ST.Loc.stVal
986 XSWI19.ST.Pos.stVal
987 XSWI20.ST.Loc.stVal
988 XSWI20.ST.Pos.stVal
989 XSWI21.ST.Loc.stVal
990 XSWI21.ST.Pos.stVal
991 XSWI22.ST.Loc.stVal
992 XSWI22.ST.Pos.stVal
993 XSWI23.ST.Loc.stVal
994 XSWI23.ST.Pos.stVal
995 XSWI24.ST.Loc.stVal
996 XSWI24.ST.Pos.stVal
997 XCBR1.ST.Loc.stVal
998 XCBR1.ST.Pos.stVal
999 XCBR2.ST.Loc.stVal
1000 XCBR2.ST.Pos.stVal
1001 XCBR3.ST.Loc.stVal
1002 XCBR3.ST.Pos.stVal
1003 XCBR4.ST.Loc.stVal
1004 XCBR4.ST.Pos.stVal
1005 XCBR5.ST.Loc.stVal
1006 XCBR5.ST.Pos.stVal
1007 XCBR6.ST.Loc.stVal
1008 XCBR6.ST.Pos.stVal
Enumeration Role
0None
1 Administrator
2 Supervisor
3 Engineer
4 Operator
5Factory
Enumeration GOOSE dataset items
Enumeration Role
0None
1 Administrator
2 Supervisor
3 Engineer
4 Operator
5 Observer
Enumeration Item
0None
1 PP/IRIG-B/PTP/SNTP
2 IRIG-B/PP/PTP/SNTP
3 PP/PTP/IRIG-B/SNTP
Enumeration Item
0None
1 Port 1 PTP Clock
2 Port 2 PTP Clock
3 Port 3 PTP Clock
4IRIG-B
5SNTP
Enumeration Item
0 Disabled
1 No Signal
2 Calibrating
3 Synchronized
4 Synchronized (No PDelay)
