2-32 L30 Line Current Differential System GE Multilin
2.5 SPECIFICATIONS 2 PRODUCT DESCRIPTION
2
The following specifications apply to filter interface modules implemented from January 2012.
The following specifications apply to filter interface modules implemented before January 2012.
These power budgets are calculated from the manu-
facturer’s worst-case transmitter power and worst
case receiver sensitivity.
The power budgets for the 1300 nm ELED are calcu-
lated from the manufacturer's transmitter power and
receiver sensitivity at ambient temperature. At
extreme temperatures these values deviate based on com-
ponent tolerance. On average, the output power decreases
as the temperature is increased by a factor 1dB / 5°C.
TYPICAL LINK DISTANCE
EMITTER, FIBER
TYPE
CABLE
TYPE
TRANSMIT
POWER
RECEIVED
SENSITIVITY
POWER
BUDGET
MAXIMUM
OPTICAL
INPUT
POWER
820 nm, Multimode 62.5/125 μm -16 dBm -32 dBm 16 dBm -8 dBm
50/125 μm -20 dBm 12 dBm
1300 nm,
Multimode
62.5/125 μm -16 dBm -32 dBm 16 dBm -8 dBm
50/125 μm -20 dBm 12 dBm
1300 nm, Single
mode
9/125 μm -15 dBm -32 dBm 17 dBm -8 dBm
1300 nm Laser,
Single mode
9/125 μm 0 dBm -34 dBm 34 dBm -8 dBm
1550 nm Laser,
Single mode
9/125 μm 5 dBm -34 dBm 39 dBm -10 dBm
EMITTER, FIBER
TYPE
TRANSMIT
POWER
RECEIVED
SENSITIVITY
POWER
BUDGET
MAX. OPTICAL
INPUT POWER
820 nm LED,
Multimode
–20 dBm –30 dBm 10 dB –7.6 dBm
1300 nm LED,
Multimode
–21 dBm –30 dBm 9 dB –11 dBm
1300 nm ELED,
Single mode
–23 dBm –32 dBm 9 dB –14 dBm
1300 nm Laser,
Single mode
–1 dBm –30 dBm 29 dB –14 dBm
1550 nm Laser,
Single mode
+5 dBm –30 dBm 35 dB –14 dBm
EMITTER TYPE CABLE
TYPE
CONNECTOR
TYPE
TYPICAL DISTANCE
BEFORE
JANUARY
2012
FROM
JANUARY
2012
820 nm LED,
multimode
62.5/125 μmST 1.65 km2 km
50/125 μmST1.65 km2 km
1300 nm LED,
multimode
62.5/125 μm ST 4 km 5 km
50/125 μm ST 4 km 5 km
1300 nm ELED,
single mode
9/125 μm ST 11.4 km 20 km
1300 nm Laser,
single mode
9/125 μm ST 64 km 65 km
1550 nm Laser,
single mode
9/125 μm ST 105 km 125 km
