3-22
L30 Line Current
Differential System
GE Multilin
3.2 WIRING
3 HARDWARE
3
V
r
esistor = 2 mA * 14 Kohm = 28 V
V
r
esistor < contact input threshold (84 V)
(EQ 3.5)
In conclusion, in this example, the c
ontact input does NOT operate falsel
y with the Burden Resistor across its input AND
when a battery ground is present.
