LOGIQ C5/C5 PRO Quick Guide Direction 5272220-100 Rev. 2 32
Device Labels
Label Icon Description
The following table describes the purpose and location of safety labels and other important information provided on the equipment
Table 6: Label Icons
Label/Icon Purpose/Meaning Location
Identification and Rating Plate Manufacture’s name and address
Date of manufacture
Model and serial numbers
Electrical ratings (Volts, Amps, phase, and frequency)
See ”Warning Label Locations” on page 48 for
more information.
Type/Class Label Used to indicate the degree of safety or protection.
IP Code (IPX1 )
IPX1: FSU-2001
Indicates the degree of protection provided by the enclosure per IEC60 529. IPX1 cannot be used in operating
room environment; IPX8 can be used in operating room environment.
Bottom of Foot Switch
Type BF Applied Part (man in the box) symbol is in accordance with IEC 878-02-03. Beside the probe connector
“ATTENTION” - Consult accompanying documents” is intended to alert the user to refer to the operator manual
or other instructions when complete information cannot be provided on the label.
Various
“CAUTION” - Dangerous voltage” (the lightning flash with arrowhead) is used to indicate electric shock
hazards.
Various
ON” indicates the power on position of the power switch.
CAUTION: This Power Switch DOES
NOT ISOLATE Mains Supply.
Refer to Chapter 3 in the Basic User Manual for
location information.
“Protective Earth” indicates the protective earth (grounding) terminal. Inside of AC adapte and Console
