GE HEALTHCARE PROPRIETARY TO GE
D
IRECTION 5394227, 12 LOGIQ S8/LOGIQ E8 SERVICE MANUAL
Section 3-10 - Printer Installation 3 - 61
3-10-2-2 UP-D25MD - Printer Settings
1.) Select Utility ->System ->Peripherals. Select the printer to adjust (UP-D25MD) from the pull-down
menu under Standard Printer Properties. Click Properties.
2.) Select Properties from Printer pull-down menu.
3.) Click Printing Preferences at the bottom of Properties Window.
4.) Select the Paper tab and select:
- Recommended Paper: UPC-24LA (large) / UPC-24SA (small)
NOTE: Paper UPC-21L and UPC-21S are also acceptable paper to use.
- Orientation: Landscape (recommended when using large paper size)
- High Speed (check mark on)
Figure 3-42 Paper page
NOTICE
!! NOTICE:
Settings for Paper Size MUST match with the used Paper (large/small) and also the right color ink
cartridge has to be used. Otherwise you will get an error message at printing.
