60 2042376-001 Rev G ©2012 General Electric Company. All rights reserved. Lullaby
TM
Warmer
6.4 Dismantling the Pillar to Leg Assembly
When the warmer is being dismantled completely, the pillar and the leg assembly are the last
components that should be dismantled.
Ensure that the other accessories and other assemblies have been removed before you proceed to
dismantle the pillar and leg assembly.
Follow the instructions given below for dismantling the pillar and leg assembly.
Note: Ensure that there are two people to dismantle the pillar to leg assembly.
Instructions to dismantle the pillar to leg assembly:
Refer section 5.4 Pillar to Leg Assembly and Height Adjustment for more details.
1. Unscrew the rear skirt.
2. Disengage the front skirt that is snapped to the rear skirt.
3. Locate the height adjustment pin into the guide pin hole.
4. Unscrew CSK M8 screws (Qty 6).
5. Ensure that one person supports the pillar while another removes the height adjustment
pin.
6. Lift the handle and carefully slide out the leg assembly from the base support.
