8-8 MAC 1200 resting ECG analysis system Revision D
2012250-095
Parts List: Field Replaceable Units (FRUs)
Table 9. Keypads MAC 1200 ST
Part Number Description
200 5766-001 Keypad MAC1200ST International
200 5767-001 Keypad MAC1200ST Europe2
200 5768-001 Keypad MAC1200ST USA
200 5769-001 Keypad MAC1200ST Japan
Table 10. MAC 1200 PWAs (version -003 board)
1
1. The -003 PWAs will only function with v6.2 software or higher.
Part Number Description
2018357-003 Non-Chinese MAC1200 -003 PWA (with v6.2 loaded)
NOTE: The following parts are no longer used on MAC1200's
shipping with the -003 PWA:
2000771-001 - PCB MODEM SUPPLY CS_M
2001795-001 - ASSY WIRE MODEM SUPPLY
MAC1200
2013503-003 Chinese MAC1200 -003 PWA (with v6.2 loaded)
NOTE: The following parts are no longer used on MAC1200's
shipping with the -003 PWA:
2000771-001 - PCB MODEM SUPPLY CS_M
2001795-001 - ASSY WIRE MODEM SUPPLY
MAC1200
Table 11. MAC 1200 PWAs (version -002 board)
Part Number Description
2000072-002 Spare PCB Control with remote start for MAC 1200
NOTE: (-002 board only) Backward compatible with all
versions prior to v6.2. Not
compatible with v6.2 or
higher
2000072-002-1 Exchange PCB (-002 board. Backward compatible with all
versions prior to v6.2. Not
compatible with v6.2 or higher)
2000771-001 PCB Modem Supply CS_M (US only, -002 board only)
2000073-002 Exchange PCB Control with remote start for MAC 1200
NOTE: Backward compatible for all versions prior to v6.2.
Not
compatible with v6.2 or higher.
