Revision D MAC 1200 resting ECG analysis system 8-9
2012250-095
Parts List: Field Replaceable Units (FRUs)
Table 12. Electronic Components / PCBs
Part Number Description
91541936 Line filter with fuse holder
30344270 Battery
38803290 PCB battery charging (old board)
93011858 PCB power supply
91208449 Fuse T 1.25 A
92916717 Battery 3 V 0.255 Ah
30344291 Pump 12 V (Standard)
38803125 PCB Pump
Table 13. Display Module Graphics
Part Number Description
2007630-001 Assembly LCD-Module Graphic (replace display PN 93011717)
43252565 LCD holder right side
43252564 LCD holder left side
Table 14. Wire Set
Part Number Description
38327399 Cable assembly MAC 1200 resting ECG analysis system
38327409 Wire set assembly for PCB mainboard
