10-28 MAC 1200/1200 ST Revision C

2012250-021

System Setup: Communication

Ergometer/Treadmill

Options: [internal], Other. Choose the exercise test device used. Selecting

Other will open a window where you can choose the appropriate option.

Confirm your selection with .
