7
Installation Instructions
PREPARE HOT WATER LINE
• The line may enter from either side, rear or floor
within the shaded area shown in Figure F.
• The line may pass through the same hole as the
electrical cable and drain hose. Or, cut an additional
1-1/2" dia. hole to accommodate the water line.
If power cord with plug is used, water line must not
pass through power cord hole.
Figure F
Water Line Connection
• Turn off the water supply.
• Install a hand shut-off valve in an accessible location,
such as under the sink. (Optional, but strongly
recommended and may be required by local codes.)
• Water connection is on the left side of the
dishwasher. Install the hot water inlet line, using
no less than 3/8" O.D. copper tubing. Route the line
as shown in Figure F and extend forward at least
18" from rear wall.
• Adjust water heater for 120°F to 150°F temperature.
• Flush water line to clean out debris.
• The hot water supply line pressure must be
20-120 PSI.
CAUTION:
Opening the door will
cause the dishwasher to
tip forward. Do not open the door
until you are ready to install the
dishwasher. If it is necessary to
open the door, hold the top of the
dishwasher securely with one
hand and hold the door with the
other hand.
ATTENTION :
Quand vous ouvrez la
porte, cela fait basculer
vers l’avant le lave-vaisselle.
N’ouvrez jamais la porte avant d’être prêt à installer
le lave-vaisselle. Si vous devez ouvrir la porte,
tenez fort le haut du lave-vaisselle avec une main
en ouvrant la porte avec l’autre.
1-1/2" Dia.
